Victron AGM Deep Cycle Battery 12V/8Ah Victron AGM Deep Cycle Battery 12V/8Ah
Victron AGM Deep Cycle Battery 12V/8Ah

Victron

Victron AGM Deep Cycle Battery 12V/8Ah

£26.40
Tax included.
BAT212070084
Compact 12V 8Ah sealed AGM deep cycle battery from Victron Energy. Maintenance free VRLA construction with low internal resistance and low self-discharge, suited to small marine electronics and backup duties.
✓ Available for collection or delivery in ~2 days

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The Victron 12V/8Ah AGM Deep Cycle battery is a sealed valve-regulated lead-acid (VRLA) battery built with absorbent glass mat technology. The electrolyte is held in a glass-fibre mat between the plates, so the battery is maintenance free, can be mounted in almost any orientation, and does not need topping up.

AGM construction gives very low internal resistance, which suits short bursts of high current as well as steady deep-cycle service. At this compact 8Ah size the battery is a practical choice for small onboard electronics, backup supplies, and portable equipment where space and weight are limited.

Lead-calcium grids and high-purity materials keep self-discharge below 2% per month at 20°C, so the battery can be stored for extended periods between charges when kept cool. As with all lead-acid batteries, avoiding repeated deep discharge prolongs service life.

PRODUCT DETAILS

  • Sealed maintenance-free VRLA AGM construction
  • 12V nominal, 8Ah rated capacity at the 20 hour rate (C20)
  • Low internal resistance for good high-current performance
  • Self-discharge below 2% per month at 20°C
  • Cycle design life of 400 cycles at 80% depth of discharge
  • Float design life of 7 to 10 years at 20°C
  • Copper terminals; compact 151 x 65 x 101 mm body, 2.5 kg

No compatible transducers listed for this product.

No spares or accessories listed for this product.

Victron SmartShunt 500A Battery Monitor

Victron SmartShunt 500A Battery Monitor

Victron BMV-712 Smart Battery Monitor

Victron BMV-712 Smart Battery Monitor

Victron Cerbo GX MK2

Victron Cerbo GX MK2

Key specifications

TechnologyFlat plate AGM (VRLA)
Nominal voltage12 V
Rated capacity (C20)8 Ah
TerminalsCopper
Weight2.5 kg

Capacity

Rated capacity at 20h discharge8 Ah

Charging

Absorption voltage14.2 - 14.6 V
Float voltage13.5 - 13.8 V
Storage voltage13.2 - 13.5 V
Maximum charge current0.2 C
Temperature compensation-24 mV/°C

Cycle life

Float design life at 20°C7 - 10 years
Cycle life at 80% DoD400 cycles
Cycle life at 50% DoD600 cycles
Cycle life at 30% DoD1500 cycles
Self-discharge at 20°C< 2 %/month

Physical

Dimensions (l×w×h)151 x 65 x 101 mm

No videos available for this product.

Does this battery need maintenance or topping up?
No. It is a sealed valve-regulated lead-acid (VRLA) AGM battery and is maintenance free for life. The electrolyte is absorbed in a glass-fibre mat, so there is nothing to top up.
What does the 8Ah rating refer to?
The rated capacity refers to a 20 hour discharge (the C20 rate) at 25°C. Effective capacity falls as the discharge current rises, and falls faster under a constant-power load such as an inverter.
What charge voltages does Victron recommend?
For cyclic use Victron recommends an absorption voltage of 14.2 to 14.6 V, a float voltage of 13.5 to 13.8 V and a storage voltage of 13.2 to 13.5 V for a 12V AGM Deep Cycle battery.
How long can it be stored without charging?
Self-discharge is below 2% per month at 20°C, so the battery can be stored for up to a year without recharging if kept in cool conditions.
