Victron AGM Telecom Battery 12V/115Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron 12V AGM Telecom battery is a 115Ah front-terminal valve-regulated lead-acid (VRLA) battery built around Absorbent Glass Mat (AGM) construction, where the electrolyte is held in a glass-fibre mat between the plates. With the connection terminals brought out to the front of the case, it is designed to be racked or installed where top access is restricted, which makes it a practical floor-space saver for boats and vehicles as well as the telecom cabinets it was originally developed for.
AGM construction gives the battery very low internal resistance, so it accepts high charge and discharge currents and is well suited to demanding loads. Lead-calcium grids and high-purity materials keep self-discharge below 2% per month at 20C, allowing long storage between charges. Rated for a 12-year float design life and more than 500 cycles at 50% depth of discharge, it suits both standby and moderate cyclic marine duty.
The battery is maintenance-free and sealed, so it can be mounted in most orientations and needs no electrolyte topping up. Charge it as a 12V AGM battery using the absorption and float voltages stated in the specifications.
PRODUCT DETAILS
- AGM (Absorbent Glass Mat) valve-regulated construction, sealed and maintenance-free
- Front-access M8 drilled flat copper terminals for racked and space-restricted installations
- 115Ah nominal capacity at 25C to an end-of-discharge voltage of 10.5V
- Low internal resistance accepts high charge and discharge currents
- Self-discharge below 2% per month at 20C for long storage between charges
- 12-year float design life at 20C
- More than 500 cycles at 80% depth of discharge; up to 1800 cycles at 30% DoD
- Cold cranking rating of 1000A at -18C
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | AGM (Absorbent Glass Mat) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 115 Ah |
| Terminals | M8 drilled flat copper, front access |
| Weight | 35 kg |
Capacity
| Rated capacity at 20h discharge | 115 Ah |
| Capacity at C20 | 115 Ah |
| Cold cranking amps (CCA) | 1000 A |
| Reserve capacity | 200 min |
Charging
| Absorption voltage | 14.4 - 14.7 V |
| Float voltage | 13.6 - 13.8 V |
| Storage voltage | 13.2 V |
Cycle life
| Float design life at 20°C | 12 years |
| Cycle life at 80% DoD | 500 cycles |
| Cycle life at 50% DoD | 750 cycles |
| Cycle life at 30% DoD | 1800 cycles |
| Self-discharge at 20°C | Less than 2 %/month |
Physical
| Dimensions (l×w×h) | 395 x 110 x 293 mm |
