Victron
Victron AGM Telecom Battery 12V/200Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron 12V AGM Telecom battery is a 200Ah front-terminal valve-regulated lead-acid (VRLA) battery built around Absorbent Glass Mat (AGM) construction, in which the electrolyte is absorbed into a glass-fibre mat between the plates. The connection terminals are brought out to the front of the case rather than the top, so the battery suits racked installations and any location where top access is restricted. It is a practical floor-space saver on boats and in vehicles, as well as in the telecom cabinets it was originally designed for.
AGM construction gives very low internal resistance, allowing the battery to accept high charge and discharge currents for demanding loads. Lead-calcium grids and high-purity materials hold self-discharge below 2% per month at 20C, so the battery can be stored for long periods between charges. With a 12-year float design life and more than 500 cycles at 50% depth of discharge, it suits both standby and moderate cyclic marine duty, and its 200Ah capacity makes it the largest battery in the Telecom range.
The battery is sealed and maintenance-free, needs no electrolyte topping up and can be mounted in most orientations. Charge it as a 12V AGM battery using the absorption and float voltages given in the specifications.
PRODUCT DETAILS
- AGM (Absorbent Glass Mat) valve-regulated construction, sealed and maintenance-free
- Front-access M8 drilled flat copper terminals for racked and space-restricted installations
- 200Ah nominal capacity at 25C to an end-of-discharge voltage of 10.5V
- Low internal resistance accepts high charge and discharge currents
- Self-discharge below 2% per month at 20C for long storage between charges
- 12-year float design life at 20C
- More than 500 cycles at 80% depth of discharge; up to 1800 cycles at 30% DoD
- Cold cranking rating of 1800A at -18C
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | AGM (Absorbent Glass Mat) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 200 Ah |
| Terminals | M8 drilled flat copper, front access |
| Weight | 60 kg |
Capacity
| Rated capacity at 20h discharge | 200 Ah |
| Capacity at C20 | 200 Ah |
| Cold cranking amps (CCA) | 1800 A |
| Reserve capacity | 400 min |
Charging
| Absorption voltage | 14.4 - 14.7 V |
| Float voltage | 13.6 - 13.8 V |
| Storage voltage | 13.2 V |
Cycle life
| Float design life at 20°C | 12 years |
| Cycle life at 80% DoD | 500 cycles |
| Cycle life at 50% DoD | 750 cycles |
| Cycle life at 30% DoD | 1800 cycles |
| Self-discharge at 20°C | Less than 2 %/month |
Physical
| Dimensions (l×w×h) | 546 x 125 x 323 mm |
