Victron
Victron AGM Deep Cycle Battery 6V/240Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Energy 6V 240Ah AGM Deep Cycle is a sealed, maintenance-free VRLA battery built on flat plate Absorbent Glass Mat construction. As a 6 volt unit it is most often used in series, with two batteries combined to form a 12V bank or four to form a 24V bank, an arrangement that suits larger house banks where individual battery weight needs to be kept manageable. The electrolyte is absorbed into a glass-fibre mat between the plates, so the battery is spill-proof and can be mounted in any orientation.
Rated at 240Ah on the 20 hour discharge, with low internal resistance, it delivers strong high-current performance for marine loads such as inverters and thrusters. Lead-calcium grids and high-purity active materials keep self-discharge below 2% per month, allowing extended storage between charges. As with any lead-acid battery, life is longest when discharges are kept shallow and the battery is recharged promptly.
It is supplied with flat copper terminals and provides 700A cold cranking and 270 minutes reserve capacity per battery.
PRODUCT DETAILS
- Sealed maintenance-free VRLA AGM construction, spill-proof and mountable in any position
- 6 volt nominal, designed for series connection into 12V or 24V banks
- 240Ah rated capacity at the 20 hour rate
- Low internal resistance for high-current loads such as inverters and thrusters
- Flat copper terminals for a reliable connection
- Self-discharge below 2% per month at 20°C from lead-calcium grids
- Float design life of 7 to 10 years at 20°C
- Cycle design life of 400 cycles at 80% DoD, 600 at 50% DoD and 1500 at 30% DoD
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | Flat plate AGM (VRLA) |
| Nominal voltage | 6 V |
| Rated capacity (C20) | 240 Ah |
| Terminals | Copper |
| Weight | 31 kg |
Capacity
| Capacity at C20 | 240 Ah |
| Cold cranking amps (CCA) | 700 A |
| Reserve capacity | 270 min |
Charging
| Temperature compensation | -12 mV/°C |
Cycle life
| Float design life at 20°C | 7 - 10 years |
| Cycle life at 80% DoD | 400 cycles |
| Cycle life at 50% DoD | 600 cycles |
| Cycle life at 30% DoD | 1500 cycles |
| Self-discharge at 20°C | <2 %/month |
Physical
| Dimensions (l×w×h) | 320 x 176 x 247 mm |
