Actisense
Actisense Micro bulk cable reel, 100 metres, UL certified cable
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Actisense A2K-BULK-100M is a 100 metre reel of genuine Actisense NMEA 2000 Lite bulk cable, used to create or extend a network backbone to whatever length an installation needs. It is supplied as bare cable with no connectors, so it is ideal for use with the Actisense QNB-1 Quick Network Block or with Field Fit Connectors, letting you cut and terminate each run to the exact length required.
The cable carries five wires in a single waterproof jacket: a power pair, a data (signal) pair and a drain wire. The drain connects to the cable shield, protecting the signal, power and ground wires from radio frequency interference and helping to reduce emissions from the cable. Lite cable can build a backbone up to 100 metres long; where a longer run is required the centre of the bus can be extended with NMEA 2000 mini cable to keep the outer Lite sections within the 100 metre maximum.
PRODUCT DETAILS
- 100 metre reel of genuine Actisense NMEA 2000 Lite backbone cable
- Supplied as bare cable, cut to length and terminate with QNB-1 or Field Fit Connectors
- Builds or extends an NMEA 2000 backbone up to 100 metres long
- Five-wire waterproof construction with shielded drain to reduce radio frequency interference
- UL certified cable (E137250, UL1277), rated 3A at 60V DC
No exploded diagram available for this product.
No compatible transducers listed for this product.
No compatible products found.
General
| Cable Type | NMEA 2000 Micro (Lite) bulk cable, bare (no connectors) |
| Reel Length | 100 m |
| Use | Create or extend an NMEA 2000 backbone; terminate with QNB-1 or Field Fit Connectors |
Electrical
| Rated Current | 3A |
| Rated Voltage | 60V DC |
| Overall DCR (braid + tape + drain) | 3.2 ohm / 1000 ft |
Mechanical
| Power Pair | 22 AWG (19 strand tinned copper), red & black |
| Data Pair | 24 AWG (19 strand tinned copper), blue & white, 120 ohm impedance |
| Drain | 22 AWG (19 strand tinned copper) |
| Braid | 37 AWG tinned copper, 65% minimum coverage |
| Jacket | 0.8 mm nominal PVC, black, 6.85 mm outer diameter |
| Reel Weight | 7.7 kg |
Approvals & Environmental
| Operating Temperature | -25°C to +75°C |
| Storage Temperature | -40°C to +85°C |
| Certification | NMEA 2000 approved, RoHS compliant, UL certified (E137250, UL1277) |
