JL Audio XDM Car and Marine Amplifier - 3 Channel - 500W - 12V
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The JL Audio XDM500/3 is a compact three-channel Class D amplifier for car and marine use, designed to run a pair of full-range speakers plus a subwoofer from a single chassis. It combines high efficiency with clean output and flexible on-board crossovers.
The main channels deliver 75 W RMS x 2 at 4 ohms (100 W x 2 at 2 ohms) while the dedicated subwoofer channel delivers 180 W at 4 ohms (300 W at 2 ohms). The main channels have a high-pass filter and the sub channel a variable low-pass filter.
PRODUCT DETAILS
- Three-channel Class D car and marine amplifier
- 75 W RMS x 2 at 4 ohms plus 180 W sub channel at 4 ohms
- 100 W x 2 and 300 W sub channel at 2 ohms
- High-pass on main channels, variable low-pass on sub channel
- Compact chassis measuring 8.52in wide x 7.09in deep x 2.05in high
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Audio
| Configuration | 3 channel (2 full-range + 1 subwoofer) |
| RMS power @ 4 ohm | 75 W x 2 + 180 W x 1 |
| RMS power @ 2 ohm | 100 W x 2 + 300 W x 1 |
| Class | Class D |
| Crossover | High-pass on main channels, variable low-pass on sub channel |
General
| Type | Car and marine 3-channel amplifier |
Installation
| Dimensions | 8.52in W x 7.09in D x 2.05in H |
| Weight | 4.8 lb (2.2 kg) |
