Iris CMAC-NVR 16-Channel IP Network Recorder, 1TB, Recorder Only
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The CMAC-NVR is the network (IP) member of the CMAC range, recording and managing Iris IP cameras and any ONVIF Profile-S compliant third-party camera over a single camera network connection. It suits a fully digital, all-IP camera installation.
This X model is the standalone network video recorder. It outputs high-definition HDMI video to chart plotters, monitors and televisions and can be viewed and controlled through a web browser or app, with built-in WiFi and remote P2P connectivity for access on board or away from the boat. Where a plotter has no HDMI input, the Iris HDMI2IP encoder module re-encodes the output as an IP stream. For full chart-plotter integration and the on-screen virtual joystick, choose the IrisControl-hosting G model instead.
The integrated recorder is fully configurable for resolution, frame rate and motion-triggered recording, and ships with a 1TB drive in a removable anti-shock caddy that is expandable as storage needs grow.
PRODUCT DETAILS
- 16-channel network video recorder for IP cameras at 1080p
- Compatible with all Iris IP cameras and ONVIF Profile-S third-party cameras
- Standalone network video recorder (no IrisControl chart-plotter app)
- High-definition HDMI video output, with optional HDMI2IP encoding for non-HDMI plotters
- View and control via web browser or app
- Supplied with 1TB anti-vibration HDD caddy, expandable storage
- WiFi and remote P2P access to view your cameras on phone, tablet or computer
- Wide 12 to 24VDC input range and rugged, compact case
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Recorder
| Type | Network video recorder (IP cameras only) |
| Channels | 16 channels |
| Camera Capacity | 16 x IP cameras at 1920 x 1080 |
| Camera Support | All Iris IP cameras and ONVIF Profile-S compliant IP cameras |
| Video Codec | H.265 |
Storage
| Storage | 1 x 2.5" SATA anti-vibration removable HDD caddy; 1TB supplied |
Compatibility
| Control Interface | Standalone network video recorder; view/control via web browser or app (no IrisControl chart-plotter app) |
Video Output
| Output | 1 x HDMI (high definition); optional HDMI2IP encoding for non-HDMI plotters |
Connectivity
| Network | RJ45 camera network plus RJ45 for IrisControl/MFD network |
| Remote Access | WiFi and remote P2P |
| USB Touch | USB touch control for supported MFDs |
Power
| Power | +12VDC to +24VDC, <2A @ 12VDC |
Environmental
| Operating Temperature | -10C to +55C |
Physical
| Dimensions | 330 x 285 x 150 mm |
