Iris CMAC-INT-002 Hybrid Camera Interface and IrisControl Host
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The CMAC-INT-002 is the hybrid, non-recording camera management interface in the CMAC range. It accepts up to eight analogue inputs across CVBS, AHD, HD-TVI and HD-CVI formats through BNC connectors, plus up to 32 IP cameras to 4K over the camera network, and presents them as a high-definition HDMI feed to a compatible multifunction display.
Hosting the IrisControl HTML5 application, it lets you upload deck plans, drag and drop camera icons, switch inputs, select quad and multi-screen views and drive PTZ cameras over RS485 using the on-screen virtual joystick or an optional IRIS595 joystick or IRIS-TE01 rotary controller. A built-in web encoder adds remote and wireless viewing, and USB touch control is supported on compatible Garmin displays. Choose a CMAC-HVR if on-board recording is required.
PRODUCT DETAILS
- Hybrid camera interface: up to 8 analogue or analogue HD (CVBS, AHD, HD-TVI, HD-CVI) plus up to 32 IP cameras
- Hosts the IrisControl HTML5 app for Garmin, Raymarine, Simrad and Furuno MFDs
- High-definition HDMI video output
- RS485 serial data output for PTZ control
- Switch cameras and select quad and multi-screen views from your MFD
- Built-in web encoder for remote and wireless connection
- USB touch control support; optional IRIS595 joystick or IRIS-TE01 rotary controller
- No on-board recording (control and switching only)
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Interface
| Type | Hybrid camera interface and IrisControl host (no recording) |
| Processor | Novatek NT98323 |
| Video Codec | H.264, H.264+, H.265 |
| Analogue Inputs | 8 x BNC for CVBS, AHD, HD-TVI, HD-CVI |
| IP Camera Capacity | Up to 32 IP cameras (to 4K resolution) |
Video Output
| Output | 1 x HDMI (high definition) |
Connectivity
| Serial Data | RS485 for PTZ control (multi-protocol) |
| Control Interface | Hosts IrisControl for Garmin OneHelm, Raymarine LightHouse, Simrad and Furuno |
| Hardware Control | USB touch (Garmin 8xxx); optional IRIS595 joystick or IRIS-TE01 rotary controller |
Power
| Power | +12VDC to +24VDC; boot peak 1.5A, 400mA nominal |
Environmental
| Operating Temperature | -10C to +55C |
Compliance
| Approvals | CE, UKCA, FCC, RoHS, REACH, NDAA compliant; EN60945 Section 9 & 10 |
Physical
| Dimensions | 280 x 192 x 60 mm |
| Weight | 0.92 kg |
