Garmin
Cortex® H1, Tethered Handset
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Garmin Cortex H1 is a tethered, wired handset that puts full control of the Cortex marine communications system in your hand. With a colour touchscreen it manages VHF radio operation, Class D DSC calling and SmartAIS collision and anchor-watch alerts, giving a clear, modern interface at the helm or any additional station.
The H1 connects to the Cortex hub over a Wi-Fi network and is powered through a bulkhead connector, so a single handset cable keeps installation tidy. It features a 3 W Class D amplifier for clear audio and an IPX8 water rating, making it suitable for exposed and protected helm positions alike. Additional handsets can extend Cortex control to multiple locations on board.
PRODUCT DETAILS
- Tethered wired handset for the Garmin Cortex marine system
- Colour touchscreen for VHF, DSC and SmartAIS control
- Connects to the Cortex hub over Wi-Fi
- 3 W Class D amplifier for clear audio
- Powered through a bulkhead connector for tidy installation
- IPX8 water rating
- Adds an extra control station on board
No exploded diagram available for this product.
No compatible transducers listed for this product.
Connectivity
| Network | Connects to Cortex hub over Wi-Fi |
Audio
| Sound output | 3 W Class D amplifier, THD < 5% @ 85 dBA |
Physical
| Dimensions (H x W x D) | 164.8 x 71.8 x 21.4 mm (6.5 x 0.8 x 0.9 in.) |
| Weight | 285 g (0.63 lb.), including power cable |
| Compass-safe distance | 80 cm (31.5 in.) |
Electrical
| Power supply | 12 or 24 Vdc |
| Maximum power | 12 W (1 A at 12 V) |
Environmental
| Operating temperature range | -25 to 55°C (-13 to 131°F) |
| Water rating | IEC 60529 IPX8 |
