Garmin
Garmin GPSMAP 751 Touch Screen GPS Chartplotter with UK Cartography
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Garmin GPSMAP 751 is a 7 inch touchscreen chartplotter supplied with detailed UK and Ireland BlueChart cartography preloaded, so it is ready to navigate British and Irish waters straight out of the box. Its bright WVGA touchscreen with pinch to zoom and a 10 Hz internal GPS receiver make planning routes and tracking your position quick and accurate.
Built for a fully connected helm, the 751 works with the Garmin Marine Network, NMEA 2000 and NMEA 0183, and supports radar, AIS, DSC, autopilot and networked sonar. An external GPS antenna can be added for flush mount installations. This is the chart only model with no built in sonar.
PRODUCT DETAILS
- 7 inch WVGA touchscreen with pinch to zoom, 800 x 480 resolution
- Preloaded UK and Ireland BlueChart cartography
- Internal 10 Hz high sensitivity GPS receiver
- Works with Garmin Marine Network, NMEA 2000 and NMEA 0183
- Supports radar, AIS, DSC, autopilot and networked sonar
- External GPS antenna supported for flush mount installs
- Chart only model; IPX7 waterproof housing
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Display
| Display size | 15.3 x 8.5 cm (6.0 x 3.4 in.), 7 in. diagonal |
| Display resolution | WVGA, 800 x 480 pixels |
| Display type | Colour touchscreen |
GPS/GNSS
| GPS receiver | Internal 10 Hz high sensitivity GPS; external GPS antenna supported |
| Preloaded charts | UK and Ireland BlueChart cartography |
| Waypoints / routes | 5,000 waypoints; 100 routes |
General
| Built-in sonar | None; networked sonar supported via compatible Garmin module |
Connectivity
| Networking | Garmin Marine Network, NMEA 2000, NMEA 0183 |
| NMEA 2000 LEN | 2 @ 9 Vdc (100 mA max.) |
Physical
| Dimensions (W x H x D) | 230 x 143 x 58 mm (9.06 x 5.63 x 2.28 in.) |
| Weight | 1.048 kg (2.31 lb.) |
| Material | Polycarbonate plastic |
| Compass-safe distance | 45 cm (17.75 in.) |
Electrical
| Input voltage | 10 to 32 Vdc |
| Max. power usage at 10 Vdc | 27 W |
| Typical current draw at 12 Vdc | 1.3 A |
| Fuse | 3 A, fast-acting |
Environmental
| Water rating | IEC 60529 IPX7 |
| Temperature range | -15 to 55 C (5 to 131 F) |
