EGIS 250A MaxiBus Busbar, Four Stud, 4 Screw
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 250A MaxiBus four-stud busbar combines four M8 (5/16 inch) studs with four screw terminals at up to 80Vdc, giving a balance of heavy cable connections and smaller branch outputs. The insert-molded busbar and studs maximise strength while the tin-plated copper conductor keeps voltage drop low under high current.
A clear polycarbonate cover allows inspection of torque markings without removal and provides break-away tabs for cable access. The busbar is FLEX system height compatible, accepts #10 (M5) or 1/4 inch (M6) mounting screws, and uses stainless steel self-locking hardware rated from -40C to 125C.
PRODUCT DETAILS
- 250A rated, 80Vdc maximum
- Four M8 (5/16 inch) studs plus four screw terminals
- Insert-molded busbar and studs for strength
- Tin-plated copper for minimal voltage drop
- Clear polycarbonate cover with break-away tabs
- FLEX system height compatible
- Stainless steel self-locking hardware
- 250A MaxiBus busbar
- Clear polycarbonate cover
- Stainless steel terminal hardware
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Current Rating | 250A |
| Maximum Voltage | 80Vdc |
Mechanical
| Studs | 4 x M8 (5/16 inch) |
| Screw Terminals | 4 |
| M8 Nut Torque | 100 in-lbs (11.3 N-m) recommended, 120 in-lbs (13.6 N-m) max |
| Mounting Holes | 4 x #10 (M5) and 2 x 1/4 inch (M6) |
| Mounting Screw Max Torque | 50 in-lbs (5.5 N-m) |
| Busbar Material | Tin-plated copper |
| Base Material | Nylon 6 30% GF |
| Cover Material | Clear polycarbonate |
Environmental
| Operating Temperature | -40C to 125C |
General
| FLEX System Compatible | Yes |
