EGIS
EGIS Dual Power Post, M10 and M8 Studs, With Cover
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS Dual Power Post pairs one M10 (3/8 inch) and one M8 (5/16 inch) stud in a single housing with an integrated cover, making outboard motor cable connections straightforward where two stud sizes ensure the correct voltage polarities are matched. The tin-plated copper conductors deliver minimal voltage drop under high current.
Flexible mounting hole provisions accept #10 (M5) and 1/4 inch (M6) screws, and stainless steel self-locking hardware ensures long-term reliability. Break-away tabs allow cable access where terminal diameter interferes with the cover.
PRODUCT DETAILS
- One M10 (3/8 inch) and one M8 (5/16 inch) stud
- Integrated cover with break-away tabs
- Two stud sizes help match correct polarity
- Suited to outboard motor cable connections
- Tin-plated copper for minimal voltage drop
- Flexible #10 (M5) and 1/4 inch (M6) mounting
- Stainless steel self-locking hardware
- Dual Power Post, M10 and M8
- Integrated cover
- Stainless steel terminal hardware
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Maximum Voltage | 80Vdc |
| Maximum Amperage | Based on attached cables |
Mechanical
| Studs | 1 x M10 (3/8 inch) and 1 x M8 (5/16 inch) |
| M8 Nut Torque | 100 in-lbs (11.3 N-m) recommended, 120 in-lbs (13.6 N-m) max |
| M10 Nut Torque | 120 in-lbs (13.6 N-m) recommended, 140 in-lbs (15.8 N-m) max |
| Mounting Holes | #10 (M5) and 1/4 inch (M6) |
| Material | Tin-plated copper |
General
| Cover | Integrated |
