EGIS MIDI 3-Way Sealed Fuse Block, M8 In / M6 Out
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS MIDI 3-Way Sealed Fuse Block protects up to three branch circuits from a single M8 power input, with each output protected by a MIDI/AMI fuse up to 200 amps and a total continuous rating of 500 amps. Sealed to IP66 and IP6K9K with a Gore-Tex vent, and ignition protected to SAE J1171, it can be mounted anywhere on a modern vessel or vehicle. The tin-plated copper busbars deliver superior electrical performance with minimal voltage drop, and large mounting holes accept 1/4 inch (M6) attachment hardware.
An easy-to-operate latching cover protects the output studs and cable terminals from inadvertent shorts and stores two spare fuses and four spare screws. Stainless steel self-locking hardware keeps connections secure, while the glass-filled nylon housing withstands demanding environments. The block is FLEX system compatible, expanding with dual, triple and quad link busbars to build complete switching and protection solutions alongside EGIS MT Series and XD Series products. Designed and made in the U.S.A. and backed by a four year warranty.
PRODUCT DETAILS
- Three protected output circuits from one M8 power input
- M8 input stud with M6 output studs
- Accepts MIDI/AMI fuses up to 200A, 500A total continuous
- Sealed to IP66 and IP6K9K, ignition protected to SAE J1171
- Tin-plated copper busbars for minimal voltage drop
- Latching cover stores two spare fuses and four screws
- FLEX system compatible via dual, triple and quad link busbars
- MIDI 3-way sealed fuse block
- Latching protective cover
- Two spare fuses and four spare screws (stored in cover)
- Stainless steel self-locking hardware
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Total Continuous Current | 500A |
| Maximum MIDI/AMI Fuse Value | 200A |
| Fuse Type | MIDI / AMI |
Mechanical
| Output Circuits | 3 |
| Input Stud Size | M8 |
| Output Stud Size | M6 |
| Ingress Protection | IP66 and IP6K9K |
| Ignition Protected | Yes, SAE J1171 |
