EGIS XD Dual Flex 2 Relay/Relay 500A, Knobs and Tinned Wires
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 8720-1550 is a dual XD Series Flex 2 module combining two independent 500A bi-stable relays (relay/relay) in a single compact, sealed housing. It replaces two separate solenoids, reducing mounting space and weight, and each relay has its own front-facing manual override knob for locking it open or closed.
Each relay is rated 500A continuous (1500A cranking) for 12V and 24V systems, draws just 1.3mA off-state, and is programmable via dip switches for relay, battery-disconnect or voltage-sensing duty. Sealed to IP67/IP6K9K with stainless-steel hardware, the module is pin-for-pin compatible with legacy ML-Series relays and links to further XD relays via the 8790/8791 busbars. Supplied with tinned flying leads.
PRODUCT DETAILS
- Two independent 500A bi-stable relays in one module
- 500A continuous / 1500A cranking per relay
- Individual manual override knobs, lockable open or closed
- Programmable relay, disconnect or voltage-sensing duty
- Sealed to IP67/IP6K9K with stainless-steel hardware
- 35-75% less mounting space than separate solenoids
- Pin-for-pin compatible with legacy ML-Series relays
- Expandable via 8790/8791 link busbars
- 1 x EGIS XD dual relay module
- Protective terminal cover
- Stainless steel mounting hardware
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Continuous Current | 500 A per relay |
| Cranking Current | 1500 A per relay |
| Voltage Range | 8-36 V DC |
| Off-State Current Draw | 1.3 mA |
| Number of Circuits | 2 |
Mechanical
| Mechanical Switching Life | 1,000,000 cycles |
| Ingress Protection | IP67 / IP6K9K |
