EGIS XD Flex L Lithium ACR Triple 500A 12/24V (DTM)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 8630-2535 is a triple-circuit XD Series Flex L module configured as a relay, a lithium-tuned automatic charging relay (ACR) and a relay, replacing three individual high-amp relays and their external link cables with one compact unit. Built on the XD bi-stable solenoid platform, it delivers 500A continuous current and up to 1500A cranking over an 8-36V DC range, with thresholds suited to modern lithium battery chemistries. The central ACR shares charge between banks while the outer relays handle load switching, replicating common multi-battery switching and charge-management layouts, and it can also consolidate multiple ACRs for three and four battery systems.
This version terminates in a sealed Deutsch DTM connector rather than flying wires, giving a clean plug-and-play installation. Each of the three circuits has its own front-facing 3-position manual override knob that forces the relay open or closed and locks it in either state, with a clear front LED and a remote LED that mirrors it. The sealed enclosure is rated to IP67/IP6K9K with an integrated Gore-Tex vent for long life in harsh environments, and stainless-steel studs with self-locking flanged nuts accept 1/4-20 or M6 hardware. Functions are configured via dip switches under the included protective cover, and off-state draw is just 1.3mA.
PRODUCT DETAILS
- Triple-circuit module arranged as relay, lithium-tuned ACR and relay
- Sealed Deutsch DTM connector for plug-and-play installation
- 500A total continuous current and 1500A maximum cranking current
- Wide 8-36V DC operating range for 12V and 24V systems
- Ultra-low 1.3mA off-state draw via advanced bi-stable solenoid design
- Individual 3-position manual override knobs lock each relay open or closed
- Front and remote LED status indication, programmable via dip switches
- Sealed to IP67/IP6K9K with integrated Gore-Tex vent and stainless studs (1/4-20 / M6)
- 1 x EGIS 8630-2535 triple XD Flex L module (relay/ACR/relay) with Deutsch DTM connector
- 3 x 3-position manual override knobs (fitted)
- Protective terminal cover
- 40-circuit weatherproof label sheet
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Continuous Current | 500 A |
| Max Cranking Current | 1500 A |
| Voltage Range | 8 - 36 V DC |
| Off-State Current Draw | 1.3 mA |
| State Change Current | 5A @ 12V DC / 3A @ 24V DC |
Mechanical
| Mechanical Switching Life | 1,000,000 cycles |
| Connector | Deutsch DTM |
| Ingress Protection | IP67 / IP6K9K |
