Garmin
Garmin NMEA2000 Transom Mount Depth and Temperature Intelliducer
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Garmin Intelliducer is a digital smart sensor that delivers depth and water-temperature data straight onto a NMEA 2000 network. Because it processes the sonar return internally and broadcasts digital readings, it integrates neatly with networked Garmin displays and instruments without occupying a sonar port.
This is the NMEA 2000 version. The 150 W transom-mount sensor reads to a maximum depth of 900 ft, operates at 160 kHz and mounts on transoms with a deadrise of 0 to 22 degrees. It ships with a 20 ft cable for connection to your NMEA 2000 backbone.
The kit includes installation instructions; follow them carefully to avoid damaging your boat.
PRODUCT DETAILS
- Digital depth and temperature smart sensor
- NMEA 2000 networked output for Garmin displays and instruments
- 150 W at 160 kHz with depth readings to 900 ft
- Transom mount for deadrise angles of 0 to 22 degrees
- Supplied with a 20 ft cable
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Model | Garmin Intelliducer (NMEA 2000) |
| Mounting type | Transom mount |
| Functions | Depth, temperature |
| Sensor type | Digital smart sensor (depth/temperature output, no sonar display) |
Sonar
| Operating frequency | 160 kHz |
| Power | 150 W |
| Maximum depth | 900 ft |
Physical
| Output protocol | NMEA 2000 |
| Cable length | 20 ft |
| Supported transom angle | 0 to 22 degrees |
Compatibility
| Compatible displays | Outputs digital depth and temperature over a NMEA 2000 network to compatible Garmin chartplotters and marine instruments. |
