Scanstrut DS-H10 Horizontal Cable Seal - Black
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Scanstrut DS-H10-BLK feeds a single cable up to 10mm through a low side entry, taking the thicker runs that a 6mm seal will not accept. Its black finish keeps these larger feeds unobtrusive against dark decks and panels.
Made from UV-stable, high-impact plastic, it maintains an IP68 watertight seal with no marine sealant required. The captive nut keeps assembly fast and allows the seal to be removed and refitted reliably whenever the cable is serviced.
PRODUCT DETAILS
- Horizontal side-entry cable seal for low-profile cable routing
- Suits cable diameters from 6 to 10 mm (0.24-0.39 in)
- Black finish to blend with dark surfaces
- Compact footprint - 77.5 mm long x 44.5 mm wide x 27 mm high
- Graduated bungs to match the exact cable size
- Horizontal cable seal body (black)
- Gasket
- Graduated sealing bungs
- Fixing screws
- Installation instructions
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Cable type | Single cable |
| Cable diameter range | 6-10 mm (0.24-0.39 in) |
| Orientation | Horizontal (side entry) |
| Waterproof rating | Watertight seal |
Dimensions
| Length | 77.5 mm (3.05 in) |
| Width | 44.5 mm (1.75 in) |
| Height | 27 mm (1.06 in) |
Materials
| Trim material | Plastic |
| Finish | Black |
| Sealing bungs | Graduated bungs included in the package |
