Mastervolt EasyCharge 6A
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Mastervolt EasyCharge 12V/6A is a compact, fixed-mount battery charger built for harsh marine environments. This is the UK plug version (product code 43310602) of the EasyCharge 6A. Fully sealed in an epoxy-filled, non-corrosive enclosure and built to IP68 waterproofing standards, it shrugs off water, salt, shock and vibration, and easily meets global regulations including CE, CSA, CEC and ABYC.
It delivers 6A at 12V and is recommended for batteries up to 120 Ah, using an automatic IUoUo three-step+ characteristic to charge wet, AGM and Gel batteries. A universal 120 to 230V input gives complete worldwide freedom, while the fully isolated output can be wired in series or parallel for higher voltage or current. Simple to use and highly efficient, it includes spark-free, short-circuit, reverse-polarity, over-voltage, current-limited and over-temperature protection for safe, fit-and-forget operation.
PRODUCT DETAILS
- 6A charge current at 12V, recommended for batteries up to 120 Ah
- UK plug version (product code 43310602) of the EasyCharge 6A
- Fully sealed, epoxy-filled non-corrosive enclosure rated to IP68
- Salt, shock and vibration tested for harsh marine environments
- Universal 120 to 230V (90 to 265V) input for worldwide use
- IUoUo automatic three-step+ characteristic charges wet, AGM and Gel batteries
- Fully isolated output, can be wired in series or parallel for higher voltage or current
- Spark-free, short circuit, reverse polarity, over voltage, current limited and over temperature protection
- Compliant with CE and ABYC
- EasyCharge battery charger with fitted AC cable and UK plug
- DC ring terminals
- User and installation manual
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General specifications
| Total charge current | 6 A at 12 V |
| Recommended battery capacity: charge (based on 50% discharged battery) | to 120 Ah |
| Nominal input voltage | 120/230 V (90-265 V), 50/60 Hz |
| AC connection | 1.2 m (4 ft) cable + UK plug |
| DC connection | ring terminals |
| Galvanic isolation | yes |
| Dimensions, hxwxd | 76 x 152 x 51 mm (3.0 x 6.0 x 2.0 inch) |
| Weight | 1.8 kg (4.0 lb) |
| Compliance | CE, ABYC |
Technical specifications
| Charge characteristic | IUoUo, automatic 3-step+ for Gel/AGM/flooded |
| Temperature range (ambient temp.) | -20 °C to 50 °C |
| Protection degree | IP68 |
| Protections | spark free, short circuit, reverse polarity, over voltage, current limited, over temperature |
| MasterBus compatible | no |
