Victron BMV-700H High Voltage Battery Monitor Kit
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron BMV-700H is a high-voltage version of the BMV-700 battery monitor, designed for systems with a battery voltage between 60 and 385 VDC. It measures battery voltage and the current passing through the supplied 500 A shunt, then calculates ampere-hours consumed, state of charge and the time remaining at the present rate of discharge.
The kit comprises the 63 mm round head unit, the 500 A / 50 mV shunt, a 10 metre RJ12 cable and a fused battery cable. No additional parts are required to read out a high-voltage bank, although the battery monitor is not isolated from the shunt and is suitable for systems with a grounded negative only. A programmable alarm and a programmable relay allow automatic warnings and load shedding.
A VE.Direct port connects the monitor to a Victron GX device or a computer, and an optional VE.Direct to Bluetooth Smart dongle adds wireless monitoring from a phone or tablet.
PRODUCT DETAILS
- High-voltage monitoring across a 60 to 385 VDC supply range
- Precise state-of-charge and time-to-go readout for a single bank
- Supplied with a 500 A / 50 mV shunt, 10 m RJ12 cable and fused battery cable
- Programmable visual and audible alarm with a 60 V / 1 A bistable relay
- VE.Direct port for connection to a GX device or computer
- Optional VE.Direct to Bluetooth Smart dongle for wireless monitoring
- Very low current draw of less than 4 mA with the back light off
- IP55-rated 63 mm round flush-mount display
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Shunt rating | 500 A / 50 mV |
| Supply voltage range | 60 - 385 VDC |
| Bluetooth | No (optional VE.Direct to Bluetooth Smart dongle) |
| Display | 63 mm diameter flush-mount |
| Protection category (IP) | IP55 (not intended for outdoor use) |
Electrical
| Current draw | < 4 mA (back light off) |
| Battery capacity range | 1 - 9999 Ah |
| Auxiliary input | Not available |
| Bistable relay | 60 V / 1 A normally open (function can be inverted) |
Resolution & accuracy
| Current resolution | ± 0.01 A |
| Voltage resolution | ± 0.01 V |
| State of charge resolution | ± 0.1 % |
| Current measurement accuracy | ± 0.4 % |
| Voltage measurement accuracy | ± 0.3 % |
Connectivity
| VE.Direct port | Yes |
Physical
| Dimensions (h×w×d) | 69 x 69 mm bezel; 52 mm body diameter; 31 mm depth |
| Shunt connection bolts | M10 |
Operating conditions
| Operating temperature range | -40 to +50 °C |
