Victron BlueSolar PWM-Light 12/24V 30A
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron BlueSolar PWM-Light charge controller 12/24V-30A is an affordable PWM controller for 12V and 24V solar systems, with automatic system voltage detection. A two-digit seven-segment display makes setup simple, and the load output pairs a low battery voltage disconnect with a lighting control function and timer, making it a good match for solar lighting installations.
Three-stage charging (bulk, absorption, float) maintains the battery, and the unit is protected against reverse polarity, overload, short circuit and over-temperature. It is a practical, budget-friendly controller for caravans, workshops, small cabins and off-grid lighting.
PRODUCT DETAILS
- PWM charge controller for 12V and 24V systems (auto detect)
- Rated charge current 30A; maximum solar voltage 28V/55V
- Load output with low battery voltage disconnect
- Lighting control function with timer
- Two-digit seven-segment display for quick setup
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Technology | PWM (pulse width modulation) |
| Battery voltage | 12/24V with automatic system voltage detection |
| Maximum solar voltage | 28 V (12V) / 55 V (24V) |
| Rated charge current | 30 A |
Charging
| Charge voltage 'absorption' | 14.2 V / 28.4 V |
| Charge voltage 'float' | 13.8 V / 27.6 V |
| Charge algorithm | Three stage (bulk, absorption, float), not programmable |
| Self-consumption | Less than 10 mA |
| Load output | Manual control with low-voltage disconnect and lighting timer |
| Low voltage load disconnect | 11.2 V / 22.4 V |
| Low voltage load reconnect | 12.6 V / 25.2 V (manual), 13.1 V / 26.2 V (automatic) |
Protection
| Protection | Battery reverse polarity (fuse), output short circuit, over temperature, overload |
Environmental
| Operating temperature | -20 to +50°C (full load) |
| Humidity | Max 95%, non-condensing |
Physical
| Grounding | Common positive |
| Power terminals | 6 mm² / AWG10 |
| Protection category | IP20 |
| Weight | 0.2 kg |
| Dimensions (h x w x d) | 70 x 133 x 33.5 mm |
Conformance
| Safety | IEC 62109-1 |
