Maretron
VESSEL MONITORING/CNTRL BK BOX
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Maretron MBB300C Black Box is a third-generation dedicated processing unit that runs Maretron N2KView vessel monitoring and control software. Unlike a PC that will run any software, the MBB300C runs only N2KView, which makes it extremely stable and focused on monitoring and controlling your vessel. It is compatible with Garmin OneHelm and Raymarine LightHouse 3.
Ruggedised for marine use, it uses a solid-state disk to withstand the pounding of waves and dissipates less than 10 watts, so no noisy internal cooling fans are needed. It connects to a monitor via VGA or HDMI at up to 2560 x 1600, while a touchscreen, keyboard, mouse or trackball connects through its USB or serial ports. Two completely isolated CAN bus connectors allow single or redundant NMEA 2000 networks, and an Ethernet port adds IP cameras, email alert notifications and Maretron cloud services.
You get the full flexibility of N2KView, configuring as many screens as you like with exactly the data you want, plus free software upgrades as new features are added.
PRODUCT DETAILS
- Dedicated black box running only Maretron N2KView for maximum stability
- Solid-state disk and fanless cooling ruggedised for marine use
- Dual isolated CAN bus ports for single or redundant NMEA 2000 networks
- VGA or HDMI video output up to 2560 x 1600 resolution
- Four USB ports plus serial for touchscreen, keyboard, mouse or trackball
- Ethernet port for IP cameras, email alerts and cloud services
- Compatible with Garmin OneHelm and Raymarine LightHouse 3
- MBB300C-01 Black Box Vessel Monitoring and Control unit
- Wall mounting brackets
- User's manual
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Video
| Video Connectors | VGA and HDMI |
| Maximum Resolution | 2560 x 1600 (VGA), 1920 x 1080 (HDMI) |
Interfaces
| USB | Two USB 3.0 and two USB 2.0 connections |
| Serial | One RS232 9-pin D connector (touchscreen) |
| Ethernet | RJ-45 Gigabit Ethernet |
| CAN Bus | Two NMEA 2000 Micro-C connectors (isolated) |
Electrical
| Operating Voltage (Dedicated Supply) | 9 to 36 Volts DC |
| Power Consumption | 10 Watts maximum |
| Operating Voltage (NMEA 2000) | 8 to 32 Volts DC |
| Load Equivalence Number (LEN) | 1 |
Mechanical
| Overall Dimensions (DxWxH) | 5.21" x 8.02" x 1.91" (132.3mm x 203.8mm x 48.5mm), excluding connectors and brackets |
| Weight | 2.27 lbs (1.03 kg) |
| Front Panel Material | Aluminium |
| Mounting | 4 x M4 VESA 75mm x 75mm, any orientation |
Environmental
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 10% to 85% RH non-condensing |
Certifications
| Standards | FCC Class A and CE Mark, NMEA 2000 |
