Scanstrut
Sub 15W 3-Coil
£109.99
/
Tax included.
Shipping calculated at checkout.
SC-CW-7GT
Sub 15W 3-Coil is a three-coil hidden charger designed with factory fit in mind. Sink it into a surface with a foam overlay on top, or mount it on the surface, to charge through non-metallic materials for a flush, clean finish. Waterproof and wired for 12/24V.
✓
Collection or delivery in 1-2 weeks
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
Sub, now with 15W three-coil technology and designed with factory fit in mind. The pioneering three-coil sub-charger bonds out of sight and powers a phone straight through non-metallic materials.
Sink it into a surface beneath a foam overlay, or install it on top, for a fit that keeps the aesthetics flush and clean while remaining easy to use. The wider three-coil charging area makes placement simple. Fully waterproof and wired for 12/24V.
PRODUCT DETAILS
- 15W three-coil charging with overlapping coils for no dead space
- Intelligent charging mirrors phone movement to maintain a constant charge at sea or off-road
- IPX6 waterproof front and back
- Sub-mount bonds beneath the surface and charges through non-metallic materials
- Rear LED indicator confirms power and charge status
- Engineered for thermal management to perform in hot climates above 30C (86F)
- 12V and 24V compatible (10-30V DC)
- 5-year warranty
- Sub 3-coil 15W charger unit
- Installation instructions, cutting and recess templates
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Range | ROKK Wireless 15W 3-Coil |
| Wireless Standard | Qi compatible, three-coil |
| Installation | Sub-mount, bonds beneath the surface |
Electrical
| Input Voltage | 10-30V DC (12/24V system) |
| Input Current (max) | 2A |
| Output Power (max) | 15W (12V, 1.25A) |
| Standby Power (max) | Less than 1.2W |
Dimensions
| Width | 85mm (3.35") |
| Length | 126mm (4.96") |
| Depth | 18.8mm (0.74") |
Environment
| Waterproof Rating | IPX6 front and back |
Approvals
| Certifications | CE, UKCA, FCC, RoHS, C-Tick, UN ECE R10, E24, PSE |
Can the charger be installed using mains power?
The ROKK Wireless range is designed for 12/24V electrical systems, but we can supply transformers that enable them to be fitted to a mains supply. As each country has its own power specification, please contact technical@scanstrut.com for more information.
Can I mount the charger overhead or in any orientation?
Yes, you can mount it in any orientation.
Will it charge through my waterproof phone case?
Yes, it will charge through any case under 3mm thick that does not contain any metal.
