Scanstrut SPH-4XI-W Helm Pod
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The SPH-4XI-W HelmPod gathers up to four standard nav instruments and an autopilot keypad into one clean housing at the helm of your sailing yacht. A stainless saddle system supports the pedestal tubing for a secure, rigid fit, with a universal helm fixing that works across a wide range of cockpit configurations.
A high tear strength silicone seal keeps the cable entry watertight, and the silicone construction resists heat and UV exceptionally well. The pod arrives uncut so the apertures can be cut to match exactly the instruments you intend to fit.
PRODUCT DETAILS
- Compact helm pod for up to four instruments or a small display
- 7 degree tilt for an ergonomic viewing angle at the helm
- Compatible with displays such as the Simrad NSS7 using self-tapping screws
- Mounts to a pedestal guard from 7 to 12 inch tube centres
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Pod type | Helm pod for pedestal guard mounting |
| Tilt angle | 7 degrees |
Compatibility
| Display capacity | Compact multi-instrument helm pod; suits up to four instruments or a small display (eg Simrad NSS7 using self-tapping screws) |
Dimensions
| Overall width | 566 mm (22.3 in) |
| Maximum cut-out area | 230 x 120 mm (9.1 x 4.7 in) |
| Face depth | 135 mm (5.3 in) |
Fixing
| Pedestal guard fitment | Fits pedestal guards from 177.8mm (7 in) to 304.8mm (12 in) tube centres; will fit up to 406mm (16 in) centres but no drilling guide provided |
| Pedestal guard tube | Stainless steel tube 25 to 33.7mm (1 to 1.33 in) diameter |
