Scanstrut
ROKK Mini Screw Down Base
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The RLS-401 Screw Down Base is the most secure mounting point in the ROKK Mini system. Fixed down with screws onto any flat surface, it gives a rock-solid foundation for a phone, tablet, small fish finder or action camera, even in rough conditions.
It is fully compatible with the RLS-AM ROKK Mini body and every ROKK Mini top plate, so you can build the exact mount your setup needs and move devices between bases around the boat in one click. Made from tough, UV-resistant materials, it is engineered to withstand the harsh marine environment year after year.
PRODUCT DETAILS
- Screw-down base for permanent mounting on a flat surface
- Four-point fixing through 4.2mm (0.17in) holes for a secure hold
- Part of the modular ROKK Mini system; pairs with the adjustable body and any top plate
- Supports a 1.2kg (2.65lbs) maximum load
- ROKK Mini screw-down base x1
- No.4 x 20 self-tapping screws x4
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Type | ROKK Mini screw-down surface base |
| Maximum load | 1.2kg (2.65lbs) |
Fixing
| Mount type | Screw-down (4 fixing holes) |
| Fixing hole diameter | 4.2mm (0.17in) |
| Hole spacing | 34 x 34mm (1.33 x 1.33in) |
Dimensions
| Base footprint | 53 x 53mm (2.08 x 2.08in) |
