Scanstrut DS21B-P Small Cable Seal - Plastic - Grey Scanstrut DS21B-P Small Cable Seal - Plastic - Grey
Scanstrut DS21B-P Small Cable Seal - Plastic - Grey

Scanstrut

Scanstrut DS21B-P Small Cable Seal - Plastic - Grey

£28.99
Tax included. Shipping calculated at checkout.
DS21B-P
The Scanstrut DS21B Small is a vertical entry cable seal configured to route two cables through a single opening, for connectors up to around 21mm. Moulded in grey high-impact plastic, it seals a twin-cable entry through a deck or bulkhead to IP68 watertight. You install it without removing the connectors, and no sealant is needed.
✓ Available for collection or delivery in ~2 days

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The Scanstrut DS21B Small shares the 21mm class of the DS21A but is configured for two cables, letting a pair of leads share one tidy opening instead of two separate seals. It is ideal where a display, sensor or accessory needs both a network and a power lead brought below decks together.

The grey low-profile dome is ultra-strong and impact-resistant, and the pre-drilled, blank and split bungs supplied let the twin-cable layout suit a range of diameters. Captive nuts make assembly fast and easy to repeat.

Both cables are routed without removing their connectors and with no sealant on the bungs, so a single neat IP68 waterproof entry serves two leads at once.

PRODUCT DETAILS

  • Watertight cable seal for routing a single larger cable through a deck or panel
  • Suits cable diameters from 9 to 14 mm (0.35-0.55 in)
  • 49 mm flange with a 45.7 mm cut-out
  • Graduated bungs to match the exact cable size
  • No messy sealant needed on the bungs
  • Supplied with stainless fixings and gasket
  • Cable seal shell x1
  • Base x1
  • Gasket x1
  • Sealing bungs x4
  • No. 6 x 16 self-tapping screws x3
  • M4 x 10 bolts x3
  • Installation instructions

No exploded diagram available for this product.

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

General

Cable typeSingle cable
Cable diameter range9-14 mm (0.35-0.55 in)
OrientationVertical (deck / top entry)
Waterproof ratingWatertight seal

Dimensions

Outer flange diameter49 mm (1.93 in)
Bore / cable opening diameter21 mm (0.83 in)
Height20.5 mm (0.81 in)

Fixing

Cut-out diameter45.7 mm (1.8 in)
Fixings3 x No. 6 x 16 self-tapping screws and 3 x M4 x 10 bolts (supplied)
Pilot hole2.5 mm (3/32 in) soft material, 3 mm (1/8 in) hard material

Materials

Trim materialPlastic
Sealing bungs4 x graduated bungs
