Scanstrut DS40-S Mini Cable Seal - Stainless Steel
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The DS40-S is the flagship Large seal in premium 316 stainless steel, made to land cables and connectors up to roughly 40mm where the biggest runs meet an exposed or highly visible entry point. It is the fast, easy and 100% waterproof route for heavy-gauge cabling below decks.
The marine-grade 316 housing resists salt-water corrosion and finishes the deck with a polished, hardware-grade face that matches stainless arches and hardtops. Captive nuts keep assembly quick and repeatable through multiple installations, while the included pre-drilled, blank and split bungs tune the Large opening to each cable diameter. No sealant is needed on the bungs, so the result stays clean and easy to service.
PRODUCT DETAILS
- Watertight cable seal for routing a single large cable through a deck or panel
- 316 stainless steel trim for a premium, corrosion-resistant finish
- Suits cable diameters from 12 to 15 mm (0.4-0.59 in)
- 69 mm flange with a 66 mm cut-out
- Graduated bungs to match the exact cable size
- No messy sealant needed on the bungs
- Cable seal shell x1 (316 stainless steel)
- Base x1
- Gasket x1
- Sealing bungs x2
- No. 6 x 16 self-tapping screws x4
- M4 x 10 bolt x1
- Installation instructions
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Cable type | Single cable |
| Cable diameter range | 12-15 mm (0.4-0.59 in) |
| Orientation | Vertical (deck / top entry) |
| Waterproof rating | Watertight seal |
Dimensions
| Outer flange diameter | 69 mm (2.72 in) |
| Bore / cable opening diameter | 40 mm (1.57 in) |
| Height | 21.7 mm (0.85 in) |
Fixing
| Cut-out diameter | 66 mm (2.6 in) |
| Fixings | 4 x No. 6 x 16 self-tapping screws and 1 x M4 x 10 bolt (supplied) |
| Pilot hole | 2.5 mm (3/32 in) soft material, 3 mm (1/8 in) hard material |
Materials
| Trim material | 316 stainless steel |
| Sealing bungs | 2 x graduated bungs |
