Victron Orion 110/24 (360W) 110V Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion 110/24 is a 110V isolated DC-DC converter rated at 360W, taking a nominal 110V DC input (60 to 140V) and delivering a regulated 24 V output. Galvanic isolation of more than 400V rms is provided between the input, output and case, suiting installations where the input and output grounds must remain separate.
The converter uses temperature-controlled fan-assisted cooling and is housed in an anodised aluminium case. It is short circuit proof and protected against overheating, reverse polarity and over voltage, the latter by a varistor that also guards against load dump. Connections are made with 6.3 mm (0.25 inch) push-on flat blade terminals.
This is a voltage converter rather than a battery charger and has no multi-stage charge algorithm. It is intended for powering DC loads from a 110V DC supply.
PRODUCT DETAILS
- Isolated 110V DC-DC converter rated 360W
- Nominal 110V DC input with a wide 60 to 140V range
- Regulated 24 V output
- Galvanic isolation greater than 400V rms between input, output and case
- Temperature-controlled fan-assisted cooling
- Short circuit proof with reverse polarity and over voltage protection
- Anodised aluminium casework
- 6.3 mm (0.25 inch) push-on flat blade connections
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 110V (60-140V) |
| Output voltage (nominal) | 24 V |
| Continuous output current | 15 A |
| Continuous output power | 360 W |
| Galvanic isolation | Isolated (> 400V rms between input, output and case) |
| Bluetooth | No |
Input
| Input voltage | 110V (60-140V) |
| Off load current | < 25 mA |
Output
| Output voltage | 24 V |
| Continuous output current | 15 A |
| Output power rating | 360 W |
| Output voltage stability | 2 % |
| Output voltage tolerance | 3 % |
| Output noise | < 50 mV rms |
| Maximum efficiency | approx. 85 % |
General
| Galvanic isolation | > 400V rms between input, output and case |
| Cooling | Fan-assisted, temperature controlled |
| Overcurrent protection | Short circuit proof |
| Overheating protection | Reduction of output voltage |
| Reverse polarity protection | Fuse and reverse connected diode across input |
| Over voltage protection | Varistor (also protects against load dump) |
Physical
| Casework | Anodised aluminium |
| Connections | 6.3 mm (0.25 inch) push-on flat blade connectors |
| Weight | 1.4 kg (3.1 lb) |
| Dimensions (h x w x d) | 82 x 132 x 190 mm (3.2 x 5.2 x 7.5 inch) |
Environmental
| Operating temperature | -20 to +40 degrees C (derate linearly to 0 A at 70 degrees C) |
| Temperature rise after 30 minutes at full load | 30 degrees C |
| Humidity | Max. 95 % non-condensing |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
