Victron Orion 12/24-8 Non-Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion 12/24-8 is a non-isolated DC-DC converter that steps a 12V supply up to a fixed 24V output, delivering up to 8A (192W continuous). It is designed to power 24V equipment from a 12V system. Unlike the adjustable models in the high-power range it has a fixed output and is not intended to buffer-charge a battery; where controlled charging is needed an Orion-Tr Smart charger should be used.
The converter holds a stable output across a 9 to 18V input and is short-circuit protected, with a quiet fanless design and a low off-load current. It suits onboard, automotive and off-grid installations where a small amount of 24V power is required from a 12V source.
Connections are made with 6.3 mm Faston tabs and the supply includes four insulated female crimp terminals, so the unit installs quickly without special tools.
PRODUCT DETAILS
- 12V to 24V non-isolated conversion at up to 8A (192W continuous)
- Fixed 24V output for running 24V equipment from a 12V system
- Efficiency of around 95 percent
- Wide 9 to 18V input range
- Fanless design with low off-load current
- 6.3 mm Faston tab connections, four crimp terminals supplied
- Fixed output, not intended for battery charging
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 9 to 18 V |
| Output voltage (nominal) | 24 V (fixed) |
| Continuous output current | 8 A |
| Continuous output power | 192 W (24 V x 8 A) |
| Galvanic isolation | Non-isolated |
| Bluetooth | No |
Input
| Input voltage range | 9 to 18 V |
| Under-voltage shutdown | 8 V |
| Under-voltage restart | 10 V |
| Off load current | < 10 mA |
Output
| Output voltage | 24 V (fixed) |
| Adjustable output | No |
| Continuous output current | 8 A |
| Maximum output current | 20 A |
| Maximum efficiency | 95 % |
| Suitable to buffer-charge a battery | No |
General
| Galvanic isolation | No |
| Fan assisted cooling | No |
| Remote on/off | No |
| Parallel operation | No |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40) |
Physical
| DC connection | Faston tabs 6.3 mm |
| Weight | 0.4 kg |
| Dimensions (h x w x d) | 45 x 90 x 115 mm |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
