Iris IRIS485 2MP IP Vari-Focal Dome Camera, White, 2.8-12mm
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The IRIS485 is the network IP model in Iris's X85 range of vari-focal marine cameras, machined from 316 marine grade stainless steel and finished in white to blend with painted superstructures. Its manually adjustable 2.8mm to 12mm lens tunes the field of view from a wide 110 degrees down to a 22 degree telephoto, so a single camera covers both close-range docking and longer-range deck surveillance.
The IRIS485 delivers Full HD 1920 x 1080 (2MP) video with H.264 and MJPEG dual streaming, ONVIF Profile S support and Power over Ethernet (IEEE802.3af). It is directly compatible with Raymarine multifunction displays running Lighthouse 2 software and above, as well as Iris network video recorders and PC based systems.
Measuring just 92.5mm high by 142mm in diameter and rated to IP66, the camera is compact enough for engine rooms and other tight spaces, with twenty-four 850nm infra-red LEDs providing clear night vision up to 30m.
PRODUCT DETAILS
- Machined from 316 marine grade stainless steel for superior corrosion resistance
- Manually adjustable 2.8-12mm vari-focal lens (110 degrees wide to 22 degrees telephoto)
- Full HD 1920 x 1080 (2MP) IP video with H.264 / MJPEG dual streaming
- Directly compatible with Raymarine chart plotters running Lighthouse 2 and above
- ONVIF Profile S and Power over Ethernet (IEEE802.3af)
- 24 x 850nm infra-red LEDs for up to 30m night vision
- IP66 rated against dust and powerful water jets
- White painted finish to match vessel superstructure
No compatible transducers listed for this product.
Camera/Imaging
| Sensor | 1/3" Panasonic CMOS |
| Resolution | 1920 x 1080 (2MP) max, multiple resolution options |
| Frame Rate | Max 30fps at 1920 x 1080P |
| Minimum Illumination | 1.0 lux colour / 0.5 lux mono / 0 lux IR on |
Lens
| Lens | 2.8-12mm vari-focal, manual adjustment / DC auto iris |
| Horizontal Field of View | 110 degrees (wide) to 22 degrees (telephoto) |
Video Output
| Video Processing | H.264 / MJPEG dual streaming supported |
Connectivity
| LAN Interface | RJ45 10/100 Base-T |
| ONVIF | ONVIF Profile S 2.4 |
Illumination (IR)
| Infra-Red | 24 x 850nm IR LEDs, up to 30m range |
Power
| Power | PoE IEEE802.3af / 12VDC plus/minus 10% |
Environmental
| Environmental Rating | IP66 (tested to EN60529) |
| Operating Temperature | -20 to +55 degrees C |
Physical
| Material | 316 marine grade stainless steel, white painted finish |
| Dimensions | 92.5mm high x 142mm diameter |
Compatibility
| MFD Compatibility | Directly compatible with Raymarine MFDs running Lighthouse 2 and above; Iris HVR/NVR systems |
