Actisense
Actisense Micro 4-Way Drop
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Actisense Micro 4-Way Drop is a single connection point that splits out to four device drops on an NMEA 2000 network, making it far easier to reach several instruments that are grouped together. Where four devices would normally each need their own T-piece and drop cable, or the backbone would have to be routed closer to them, the 4-Way Drop brings a single 2 m lead to the cluster and provides four female connection points from it.
The assembly terminates in one male connector for the backbone side and four female connectors for the device drops, and uses the same UL-certified Micro cable and gold-plated contacts as the rest of the Actisense connector range. As with any NMEA 2000 network, the total drop length to any device must not exceed 6 m. It is backed by the standard 5 year Actisense guarantee.
PRODUCT DETAILS
- Single connection point splits a backbone drop into four device connections
- Cuts installation time, cabling and cost compared with four separate T-pieces and drops
- Four female connectors plus one male connector on a 2 m Micro lead
- Uses UL-certified Actisense Micro cable with gold-plated contacts for reliable marine connections
- Fully NMEA 2000 certified and compatible with other NMEA 2000 hardware
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Connections
| Configuration | 4 x female, 1 x male |
| Connector type | NMEA 2000 Micro (M12) |
| Cable length | 2 m |
Installation
| Maximum drop length | 6 m (per NMEA 2000 network rules) |
Approvals
| Certification | NMEA 2000 Approved |
General
| Guarantee | 5 years |
