Actisense Micro cable assembly 4 metre, UL certified cable
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Actisense A2K-TDC-4M is a 4 metre NMEA 2000 Micro cable assembly, fitted with a male connector at one end and a female connector at the other so it plugs straight into a standard NMEA 2000 network. It can be used as a drop cable to connect an instrument to the backbone, or to extend the backbone itself.
Only genuine Actisense UL certified cable is used, so the assembly carries the same quality reassurance as the rest of the range. The cable carries five wires in a single waterproof jacket: a power pair, a data (signal) pair and a drain wire. The drain connects to the cable shield, protecting the signal, power and ground wires from radio frequency interference and helping to reduce emissions from the cable. The moulded M12 connectors give a secure, IP67 rated connection once mated.
PRODUCT DETAILS
- 4 metre NMEA 2000 Micro cable assembly, male connector one end and female connector the other
- Works as a drop cable to a device or as a backbone extension
- Genuine Actisense UL certified cable (E137250, UL1277) for quality reassurance
- Five-wire waterproof construction with shielded drain to reduce radio frequency interference
- IP67 rated M12 connectors for a secure, weatherproof connection when mated
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Cable Type | NMEA 2000 Micro (Lite), UL certified cable |
| Length | 4 m |
| Connectors | NMEA 2000 Micro, male one end and female other end |
| Use | Drop cable or backbone extension |
Electrical
| Rated Current | 3A |
| Rated Voltage | 60V DC |
Mechanical
| Power Pair | 22 AWG (19 strand tinned copper) |
| Data Pair | 24 AWG (19 strand tinned copper) |
| Drain | 22 AWG (19 strand tinned copper) |
| Braid | 37 AWG (tinned copper) |
| Jacket | 0.8 mm nominal PVC, black, 6.85 mm outer diameter |
| Mating Thread | M12, standard A-polarisation |
Approvals & Environmental
| Protection | IP67 (when mated) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Certification | NMEA 2000 approved, RoHS compliant, UL certified (E137250, UL1277) |
