Garmin
Fusion Apollo RA670
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The newest member of the Apollo family, the Fusion RA670 inherits key audio innovations from the award-winning RA770 in a compact form factor. Fusion Digital Signal Processing, over-the-air software updates and a broad choice of sources, including optical audio for connection to salon and cabin TVs, make it simple to enjoy superior sound in any area of the boat.
Multi-Zone technology gives independent control of up to three zones, while PartyBus networking links additional Apollo stereos and remotes across the vessel. Bluetooth, USB, AM/FM and DAB+ (module required) sources plus NMEA 2000 connectivity round out a genuinely capable helm stereo.
PRODUCT DETAILS
- Apollo audio innovation and DSP in a compact form factor
- Multi-Zone technology controls up to three independent zones
- Optical audio input for connection to salon and cabin TVs
- PartyBus networking links additional Apollo stereos and remotes
- 2.7 in optically bonded colour display with NMEA 2000 connectivity
- Apollo RA670 marine stereo
- Trim ring and mounting hardware
- Wiring harness
- Stealth antenna
- Installation instructions
No exploded diagram available for this product.
No compatible transducers listed for this product.
No compatible products found.
Audio
| Built-in amplifier power | 26 W RMS x 4 (4 Ohm), 43 W RMS x 4 (2 Ohm) |
| Peak power | 280 W |
| Amplifier class | Class-D (2 Ohm stereo-stable) |
| Zones | 3 |
| DSP | Built-in Fusion Digital Signal Processing |
| Pre-amp / RCA outputs | Zone RCA pre-outs plus subwoofer output |
Sources
| Bluetooth | Yes |
| USB | Yes |
| AM/FM tuner | Yes |
| DAB+ | Optional (DAB+ module required) |
| AUX | Yes |
| Optical audio | Yes |
| Apple / Android | iAP2 and Android AOA |
Display
| Display type / size | 2.7 in optically bonded colour LCD |
Connectivity
| NMEA 2000 | Yes |
| Ethernet (PartyBus) | Yes (wired) |
| Wired remote support | Yes (Apollo ERX400 / NRX remotes) |
Installation
| Mounting | Flush / surface mount |
| Dimensions (H x W x D) | 68 x 157 x 123 mm |
| Cut-out (W x H) | 135 x 52 mm |
| Marine rating | IPX6 and IPX7 front panel |
General
| Power supply | 10.8 to 16 V DC |
| Warranty | 2 years |
