Scanstrut SC30 Satcom Antenna Mount
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Scanstrut SC30 lifts your satcom or TV antenna clear of arches, rails and other obstructions, giving the dome an unobstructed line of sight for the best possible reception.
Sized for compact Mini-format satcom and TV antennas, the SC30 uses pre-drilled mounting holes and external fixings so your chosen antenna bolts straight on, while cabling is routed neatly through the base and the mount fixings stay hidden for a tidy finish.
Moulded as a single piece of high-strength composite GRP, it is corrosion-free and built to last in the marine environment.
PRODUCT DETAILS
- Raises a satcom dome above deck clutter for a clear satellite view
- Pre-marked for KVH, Intellian and Thrane & Thrane domes
- Composite GRP moulding with white gel coat finish
- Internal cable routing
- SC30 composite satcom mount
- Weather seal (for use with KVH FB150/250 compact and Thrane & Thrane F33)
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Mount type | Satcom antenna mount |
Dimensions
| Overall height | 255mm (10.0") |
| Base footprint | 163mm x 144mm (6.42" x 5.68") |
Fixing
| Base hole centres | 66mm x 66mm (2.60" x 2.60") |
| Base hole diameter | 8.5mm (0.33") |
| Cable routing hole | 30-50mm (1 1/4" - 2") |
| Deck fasteners | 4x M8 (length to suit, not supplied) |
Compatibility
| Compatible antennas | KVH M1 (163mm x 163mm pattern); KVH FB150/250 compact and Thrane & Thrane F33 (175.4mm PCD); Intellian i1, i2 (140mm x 140mm pattern) |
Materials
| Material | 8mm composite GRP |
| Finish | White gel coat |
