Simrad
Simrad Tillerpilot TP10
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Manufacturer-backed extended cover provided by Navico — add up to 3 extra years.
Extended cover is added to your order and confirmed with your warranty documentation.
Description
The Simrad TP10 is the entry model in the Simrad Tillerpilot range, designed for tiller-steered sailing yachts up to 12 m (39 ft) overall. It pairs sophisticated electronics and steering software with a powerful screw-thread drive to hold a steady course with minimal current draw, leaving the helm free for sail trim and navigation.
A built-in fluxgate compass provides heading reference, with adjustable Response Control and a Seastate filter to tune steering to the conditions. Five keys give access to all functions, including auto-tack, and the unit mounts on a supplied tillerpin and cup that allow it to be fitted and stowed in seconds.
PRODUCT DETAILS
- Entry model in the Simrad Tillerpilot range
- For tiller-steered sailing yachts up to 12 m (39 ft)
- Powerful screw-thread drive with minimal current draw
- Built-in fluxgate compass for heading reference
- Adjustable Response Control and Seastate filter
- Five-key operation including auto-tack
No exploded diagram available for this product.
No compatible transducers listed for this product.
No compatible products found.
General
| Boat length (max) | 12 m (39 ft) |
Electrical
| Supply voltage | 12 V (10-16 V) DC |
| Current consumption | Standby 60 mA, Auto 500 mA (typical) |
Drive
| Drive system | Screw thread |
| Peak thrust | 65 kg (143 lbs) |
| Operating stroke | 250 mm (10 in) |
| Hardover time | 6.9 s at 0 kg, 8.0 s at 20 kg |
Environmental
| Operating temperature | -10 C to +55 C (14 F to 131 F) |
Physical
| Length at mid-stroke | 610 mm (24 in) |
| Mounting | Starboard as default (reversible) |
