Victron Quattro 48/3000/35-50 120V
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Quattro 48/3000/35-50/50 is a combined inverter and battery charger for 120 VAC North American marine and off-grid systems running from a 48 volt battery bank. It delivers 3000 VA of continuous pure sine wave power together with a 35 amp charger, making it well suited to systems where higher DC voltage keeps cable sizes and losses down.
The Quattro has two AC inputs with an integrated transfer switch. It automatically connects to whichever source is active, for example the public grid and a generator, and switches over in under 20 milliseconds so sensitive electronics keep running without interruption. A second AC output powers non-critical loads only when an external source is present.
PowerControl and PowerAssist let you set a current limit on each input and boost limited shore or generator power with energy from the battery, avoiding nuisance tripping. The unit is lithium-ion battery compatible and integrates with Victron GX devices and the VRM portal for on-site and remote monitoring.
PRODUCT DETAILS
- 3000 VA continuous pure sine wave output at 120 VAC, 60 Hz
- 35 A house battery charger
- Two AC inputs with integrated transfer switch (under 20 ms changeover)
- PowerControl and PowerAssist boost limited shore or generator power
- Second AC output for non-critical loads
- Split-phase and three-phase capable, parallel up to 6 units
- Lithium-ion battery compatible
- Monitoring and control via GX devices, VictronConnect and the VRM portal
No compatible transducers listed for this product.
Key specifications
| System voltage | 48 V |
| Continuous output power | 3000 VA |
| Continuous output power at 25°C | 2400 W |
| Peak power | 6000 W |
| Maximum charge current | 35 A |
| Transfer switch | 2x 50 A |
AC inputs
| Number of AC inputs | 2 |
| AC input voltage range | 90 - 140 VAC |
| AC input frequency | 55 - 65 Hz |
| Maximum feed-through current | 2x 50 A |
Inverter
| DC input voltage range | 38 - 66 V |
| Output voltage / frequency | 120 VAC ±2%, 60 Hz ±0.1% |
| Cont. output power at 25°C (VA) | 3000 VA |
| Cont. output power at 25°C (W) | 2400 W |
| Cont. output power at 40°C (W) | 2200 W |
| Cont. output power at 65°C (W) | 1700 W |
| Peak power | 6000 W |
| Maximum efficiency | 94% |
| Zero load power | 25 W |
| Zero load power in Search mode | 12 W |
| Zero load power in AES mode | 20 W |
Charger
| Charge voltage 'absorption' | 57.6 V |
| Charge voltage 'float' | 55.2 V |
| Storage mode | 52.8 V |
| Charge current house battery | 35 A |
| Battery temperature sensor | Yes |
Connectivity & control
| VE.Bus communication port | Yes, for parallel, split phase and three phase operation, remote monitoring and system integration |
| General purpose comms port | 2x |
| Number of programmable relays | 3x |
| Auxiliary output | 32 A |
| Remote on/off | Yes |
Protection
| Protection | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 120 VAC on inverter output, input voltage ripple too high |
Environmental
| Operating temperature range | -40 to +65°C |
| Humidity (non-condensing) | Max 95% |
Physical
| Material & colour | Aluminium, blue RAL 5012 |
| Protection category | IP21 |
| Battery connection | Four M8 bolts (2 plus and 2 minus connections) |
| 230 VAC connection | Screw terminals 13 mm² (6 AWG) |
| Weight | 19 kg (42 lb) |
| Dimensions (h x w x d) | 362 x 258 x 218 mm |
Conformance
| Safety | EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
