XSONIC AIRMAR CM599LH-W
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Airmar CM599LH-W is a chirp-ready cavity-mount transducer that is bonded into a fluid-filled chamber inside the hull, shooting through the fibreglass so no external fitting breaks the waterline. It pairs a 28 to 60 kHz low band with a 150 to 250 kHz high band, giving 132 kHz of total bandwidth and true broadband performance from an in-hull installation.
The high channel holds a constant 25 degree wide beam for extensive coverage and clean fish arches in the upper water column, while the low channel narrows from 23 to 9 degrees athwartships to focus energy for deep bottom tracking. Low-band reach extends to around 3,000 metres, with the high band detailing the top 150 metres.
With 3 kW available on the low band and 1 kW on the high band plus a fast-response temperature sensor, the CM599LH-W suits owners who want serious CHIRP capability without a protruding thru-hull, connecting to compatible Simrad, Lowrance and B&G sounders via the xSonic connector.
PRODUCT DETAILS
- Dual-band CHIRP: 28-60 kHz low and 150-250 kHz high
- Constant 25 degree wide high beam for broad upper-water coverage
- High power: 3 kW low band and 1 kW high band
- Cavity-mount design shoots through the hull with no external fitting
- Deep-water reach to around 3,000 m on the low band
- xSonic connector for Simrad, Lowrance and B&G systems
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Acoustic
| Frequency | CHIRP: 28-60 kHz (low) and 150-250 kHz (high) |
| Total Bandwidth | 132 kHz |
| Power Rating | 3 kW (low band) / 1 kW (high band) |
Beam
| Low Band Beamwidth | 23 to 9 degrees port-starboard, 11 to 5 degrees fore-aft |
| High Band Beamwidth | Constant 25 degrees |
Functions
| Measurements | Depth and water temperature |
| Max Depth (low) | To 3,048 m (10,000 ft) |
| Max Depth (high) | To 152 m (500 ft) |
Physical
| Mount Type | Cavity mount (in-hull) |
Connection
| Connector | xSonic (swappable connector housing) |
