B&G WTP3 Serial Interface, CAN cable and CAN T-piece B&G WTP3 Serial Interface, CAN cable and CAN T-piece
B&G WTP3 Serial Interface, CAN cable and CAN T-piece

B&G

B&G WTP3 Serial Interface, CAN cable and CAN T-piece

£1,090.00
Tax included. Shipping calculated at checkout.
000-10308-001
The B&G WTP3 Serial Interface module provides serial data acquisition for the WTP3 system, interfacing RS232, RS422, RS485 and NMEA 0183 devices. It offers two bi-directional COM ports supporting baud rates from 1,200 to 115,200 and connects to the CPU over the CAN network. Supplied with a CAN cable and CAN T-piece.
✓ Collection or delivery in 1-2 weeks

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Navico Extended Warranty

Manufacturer-backed extended cover provided by Navico — add up to 3 extra years.

Extended cover is added to your order and confirmed with your warranty documentation.

Description

The WTP3 Serial Interface is one of two module types that act as the link between the system's sensors and devices and the WTP3 CPU. It handles serial data acquisition, providing two bi-directional COM ports that support RS232, RS422, RS485 and NMEA 0183 devices at baud rates from 1,200 to 115,200, making it ideal for interfacing GPS receivers, NMEA sensors and other serial equipment. The module is powered from the CAN bus and can in turn supply power to connected sensors, and it can be located anywhere on the CAN network using DIP switches to set a unique device address. A diagnostic LED shows power and data activity at a glance. Supplied with a CAN cable and CAN T-piece for connection to the network.

PRODUCT DETAILS

  • Serial data-acquisition module for the B&G WTP3 system
  • Two bi-directional COM ports
  • Supports RS232, RS422, RS485 and NMEA 0183 devices
  • Baud rates from 1,200 to 115,200
  • Powered from the CAN bus and can supply connected sensors
  • DIP-switch device addressing and a diagnostic status LED
  • Supplied with CAN cable and CAN T-piece

No exploded diagram available for this product.

No compatible transducers listed for this product.

No spares or accessories listed for this product.

B&G WTP3 CPU

B&G WTP3 CPU

General

TypeWTP3 serial data-acquisition module

Ports

COM Ports2 x bi-directional
ProtocolsRS232, RS422, RS485, NMEA 0183
Baud Rates1,200 to 115,200

Connectivity

NetworkCAN bus (connects anywhere on the network)
AddressingDIP-switch device number

Electrical

PowerPowered from CAN bus; can supply connected sensors

Features

Diagnostic LEDPower and data activity indicator

In the Box

Supplied WithCAN cable and CAN T-piece
