Victron Lynx Shunt VE.Can
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Lynx Shunt VE.Can combines a main system fuse holder and a precision battery monitor in a single Lynx Distribution module. It carries a positive busbar with space for the main system fuse and a negative busbar fitted with a shunt, so it measures battery current, voltage and state of charge at the heart of the DC system.
Battery data is shared over VE.Can and NMEA 2000, which means it integrates directly with a Victron GX device and the VRM portal for local and remote monitoring, and reports onto a marine NMEA 2000 network. A temperature sensor is included for temperature-compensated readings, and a potential-free alarm contact can drive external alarms. The shunt is suitable for all battery types, making it the natural choice where a Lynx Smart BMS is not required.
Rated for 1000 A continuous at 12, 24 or 48 V, the Lynx Shunt VE.Can bolts to other Lynx modules to build a complete busbar with battery monitoring and central fusing. It ships ready to monitor, with two VE.Can RJ45 terminators and the temperature sensor in the box. The M10 version uses M10 busbar joints, while the fuse and cable connections are M8; a Mega, ANL or CNN fuse is fitted in the main fuse position and is sold separately.
PRODUCT DETAILS
- Built-in battery monitor (shunt) measuring current, voltage and state of charge
- Main system fuse holder for central DC protection (fuse sold separately)
- VE.Can and NMEA 2000 communication for GX devices, VRM and marine networks
- Temperature sensor included for temperature-compensated monitoring
- Potential-free alarm contact rated 3 A at 30 Vdc / 250 Vac
- Suitable for all battery types where a Lynx Smart BMS is not required
- 1000 A continuous rating at 12, 24 or 48 V; ships with two VE.Can terminators
No compatible transducers listed for this product.
Key specifications
| Continuous current | 1000 A continuous |
| System voltage | 12 / 24 / 48 V |
| Connection studs | M10 busbar joints; M8 fuse and cable studs |
| Communication | VE.Can, NMEA 2000 |
| Protection rating | IP22 |
| Number of outputs | 1 (single main fuse holder) |
Electrical
| Continuous current rating | 1000 A continuous |
| Voltage range | 9 - 70 Vdc |
| Supported system voltages | 12, 24 or 48 V |
| Reverse polarity protection | No |
| Power consumption | 60 mA @ 12 V / 33 mA @ 24 V / 20 mA @ 48 V |
| Fuse type | M8 fuse holder; accepts Mega, ANL or CNN fuse, sold separately; ships with fuse-dummy busbar |
| Potential-free alarm contact | 3 A, 30 Vdc / 250 Vac |
Connections
| Busbar stud size | M8 or M10 |
| Number of fused outputs | 1 (single main fuse) |
| Fuse holder size | M8 (Mega fuse on M6 bolts) |
| Busbar material | Tinned copper |
| Busbar dimensions (HxW) | 8 x 30 mm |
Communication & control
| VE.Can | RJ45 and RJ45 terminator (two terminators included) |
| NMEA 2000 | Yes |
| Battery monitor (shunt) | Yes |
| Temperature sensor | Included |
Mechanical
| Enclosure material | ABS |
| Dimensions (HxWxD) | 190 x 180 x 80 mm |
| Weight | 1.4 kg |
Environmental
| Operating temperature range | -40 to +60°C |
| Storage temperature range | -40 to +60°C |
| Humidity | Max 95% (non-condensing) |
| Protection category | IP22 |
Standards
| Safety | EN-IEC 63000:2018 |
| EMC | EN-IEC 61000-6-3 |
| Quality (QMS) | ISO 9001:2015 |
