Victron Lynx Power In (M10)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Lynx Power In is a passive busbar module at the heart of the modular Lynx Distribution system. It provides a positive and a negative tinned-copper busbar with four heavy-duty connections for batteries, loads or chargers, plus a dedicated ground connection, all behind a removable front cover.
Rated for 1000 A continuous at 12, 24 or 48 V, the Lynx Power In lets you parallel several batteries or feed large inverter/charger loads through a single, tidy connection point. It contains no fuses or electronics, so every connected circuit must be fused externally. Multiple Lynx Power In modules can be bolted together to extend the busbar and add more connections.
With its ABS enclosure, IP22 protection and wide operating temperature range, it is well suited to demanding marine and off-grid DC installations. M10 refers to the busbar joints between modules; the cable connections themselves are M8.
PRODUCT DETAILS
- Positive and negative tinned-copper busbars with four DC connections plus a ground point
- 1000 A continuous current rating at 12, 24 or 48 V system voltage
- Passive busbar with no internal fuses; all connected circuits must be fused externally
- Modular Lynx design, bolt several modules together to extend the busbar
- M10 busbar joints between modules, M8 cable and lug connections
- Rugged ABS enclosure with IP22 protection and removable front cover
- Wide operating temperature range from -40 to +60 degrees C
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Continuous current | 1000 A continuous |
| System voltage | 12 / 24 / 48 V |
| Connection studs | M10 busbar joints (M8 cable studs) |
| Protection rating | IP22 |
| Number of outputs | 4 (unfused) |
Electrical
| Continuous current rating | 1000 A continuous |
| Voltage range | 9 - 60 Vdc |
| Supported system voltages | 12, 24 or 48 V |
| Fuse type | None (external fusing required) |
Connections
| Busbar stud size | M8 or M10 |
| Number of fused outputs | None (unfused busbar) |
| Busbar material | Tinned copper |
| Busbar dimensions (HxW) | 8 x 30 mm |
Mechanical
| Enclosure material | ABS |
| Dimensions (HxWxD) | 290 x 170 x 80 mm |
| Weight | 2.1 kg |
Environmental
| Operating temperature range | -40 to +60°C |
| Storage temperature range | -40 to +60°C |
| Humidity | Max 95% (non-condensing) |
| Protection category | IP22 |
