Raymarine
Raymarine SeaTalk ng Starter Kit
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Raymarine cover is 2 years (3 with 90-day registration). Add 1 or 2 more years with HME Care Plus.
Extended cover is added to your order and confirmed with your warranty documentation.
Description
The Raymarine SeaTalkng Starter Kit contains everything needed to build a small SeaTalkng network and connect your first device. The 5-way connector acts as a short backbone; your SeaTalkng product connects to it via the supplied spur cable, the power cable energises the network and the two terminators complete the circuit.
It is the simplest way to get a single instrument, display or sensor up and running, and the network can be expanded later with backbone cables and T-pieces.
PRODUCT DETAILS
- Complete starter network in one box
- 5-way connector forms a short backbone
- Includes 3 m spur cable and power cable
- Two terminators to complete the circuit
- Expandable with backbone cables and T-pieces
- 1 x A06064 SeaTalkng 5-Way Connector
- 2 x A06031 SeaTalkng Backbone Terminators
- 1 x A06040 SeaTalkng Spur Cable 3m
- 1 x A06049 SeaTalkng Power Cable 2m
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Raymarine Element 9 HV Chartplotter with HyperVision Sonar
Raymarine Element 12 HV Chartplotter with HyperVision Sonar
Raymarine Axiom 2 Pro 9 RVM
Raymarine Axiom 2 XL 24 Chartplotter
Raymarine Axiom 2 Pro 16 S
Raymarine Axiom 2 Pro 12 RVM
Raymarine Element 9 S Chartplotter with CHIRP Sonar
Raymarine Axiom 2 Pro 9 S
Raymarine Axiom 2 Pro 16 RVM
Raymarine Axiom 2 XL 16 Chartplotter
Raymarine Axiom 2 XL 22 Chartplotter
Raymarine Axiom 2 XL 19 Chartplotter
Raymarine Element 7 S Chartplotter with CHIRP Sonar
Raymarine Element 7 HV Chartplotter with HyperVision Sonar
Raymarine Axiom 2 Pro 12 S
Raymarine Element 12 S Chartplotter with CHIRP Sonar
General
| Type | SeaTalkng starter kit |
| Backbone element | A06064 5-way connector |
| Spur cable | A06040 (3m) |
| Power cable | A06049 (2m) |
| Terminators | 2 x A06031 |
No videos available for this product.
