Garmin
Garmin gWind Wireless Transducer Only
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
This is the Garmin gWind Wireless masthead wind transducer supplied on its own as a replacement head. It removes the need to run wires down the mast: the twin-fin design with a 3-bladed propeller and optical sensor reading transmits wind data wirelessly, giving accurate True Wind Speed in light air and a stable True Wind Angle.
An integrated solar panel keeps the internal batteries charged, with a service life of around three years and easy replacement. Wind data reaches the boat through the included WSI connection box and a Garmin GND 10 black box bridge, allowing the Nexus Network and compatible Garmin chartplotters and instruments to share it over NMEA 2000.
Supplied as the transducer only, this configuration makes it straightforward to replace an existing gWind Wireless sensor.
PRODUCT DETAILS
- Replacement gWind Wireless masthead transducer (transducer only)
- Wireless transmission, no mast cabling required
- Twin-fin design with 3-bladed propeller and optical reading
- Solar-charged internal battery, around three year life
- Uses the WSI box and a GND 10 bridge for NMEA 2000
No exploded diagram available for this product.
No compatible transducers listed for this product.
Garmin GND 10 Black Box Bridge between gWind and NMEA2000
Garmin GMI 20 Marine Instrument Display with Colour LCD 4 inch
Garmin GNX 20 Marine Instrument with Standard Monochrome LCD 4 inch
Garmin GNX 21 Marine Instrument with Inverted Monochrome LCD 4 inch
Garmin GNX Wind Marine Instrument LCD 4 inch
Garmin GNX 120 7 inch Large Format Marine Instrument Display
Garmin GNX 130 10 inch Large Format Marine Instrument Display
General
| Sensor type | Wireless masthead wind transducer (replacement head only) |
| Measurement | Apparent wind speed and angle via twin-fin design with 3-bladed propeller and optical sensor reading |
| Power source | Integrated solar panel with internal solar-charged batteries, approximately 3 year service life and user-replaceable |
| Mounting | Mast head, horizontal surface (pole mount or included bracket) |
Wind
| Wind speed range | 0.9 to 90 kn (0.5 to 50 m/s) |
Physical
| Operating temperature | -20 C to 50 C |
| Water resistance | IEC 60529 IPX-6 |
Compatibility
| Compatible systems | Transmits wirelessly via the included WSI connection box and a Garmin GND 10 black box bridge to share wind data between the Nexus Network, NMEA 2000 and compatible Garmin chartplotters and GMI/GNX instruments. |
