Mastervolt Mass Battery Charger with 3 x 400V Inputs (24V / 100A)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Mastervolt Mass 24/100-3ph is a 24V/100A battery charger built for the toughest professional, semi-professional and recreational conditions. It runs from a three-phase 400V AC supply (365 to 550V, 50/60 Hz), making it ideal for larger vessels and industrial installations where a balanced three-phase feed is available. Even under extreme conditions the Mass series operates faultlessly, delivering round-the-clock output when it is needed.
Housed in a lightweight, anodised aluminium casing, the charger has internal components coated to prevent damage from damp or condensation for a longer lifespan. It charges every battery type, including Lithium Ion, using an automatic three-step+ characteristic and communicates directly with the battery over the integrated MasterBus network. The Current Control function prevents fuses from blowing when the input voltage drops, and parallel switching allows multiple chargers to work together.
PRODUCT DETAILS
- Three-phase 400V AC input (365 to 550V, 50/60 Hz) for larger installations
- 24V nominal output with 100A total charge current at 28.5V
- Suits battery banks of 200 to 1000 Ah, charges all battery types including Lithium Ion
- IUoUo automatic three-step+ charge characteristic for Gel, AGM, wet and Lithium Ion
- Lightweight anodised aluminium casing with coated internals to resist damp and condensation
- MasterBus compatible for central, local or remote monitoring and control
- Current Control function prevents fuses blowing when the voltage drops
- Parallel switching of multiple chargers and GMDSS compatibility
- Temperature sensor included; compliant with CE, ABYC A-31, RRR and RMRS
- Mass 24/100-3ph battery charger
- Battery temperature sensor
- User manual
No compatible transducers listed for this product.
Mastervolt Battery Temperature Sensor (15m Cable)
Mastervolt MasterBus cable 0.2 metre
Mastervolt MasterBus cable 0.5 metre
Mastervolt MasterBus cable 1 metre
Mastervolt MasterBus cable 3 metre
Mastervolt MasterBus cable 6 metre
Mastervolt MasterBus cable 10 metre
Mastervolt MasterBus terminator
Mastervolt MasterBus USB Interface
Mastervolt MasterBus Modbus Interface
Mastervolt MasterBus NMEA2000 interface
Mastervolt MasterBus Serial Interface
Mastervolt MasterBus Multi Purpose Contact Output
General specifications
| Nominal output voltage | 24 V |
| Total charge current | 100 A at 28.5 V |
| Number of battery outlets | 1 |
| Battery bank size | 200-1000 Ah |
| Nominal input voltage | 3 x 400 V (365-550 V), 50/60 Hz |
| Input voltage range | 365-550 V |
| Power supply mode | yes |
| Galvanic isolation | yes |
| Display/read-out | LED display |
| Dimensions, hxwxd | 420 x 318 x 130 mm (16.5 x 12.5 x 5.1 inch) |
| Weight | 7.7 kg (17.0 lb) |
| Compliance | CE, ABYC A-31, RRR, RMRS |
Technical specifications
| Charge characteristic | IUoUo, automatic 3-step+ for Gel/AGM/wet/Lithium Ion |
| Charge voltage Bulk | 28.5 V |
| Charge voltage Absorption | 28.5 V |
| Absorption time | 4 hours |
| Charge voltage Float (wet batteries) | 26.5 V |
| Charge voltage Float (Gel/AGM batteries) | 27.6 V |
| Temperature sensor | yes (included) |
| DC voltage compensation | yes |
| Power consumption (DC side) | < 1 mA |
| Full load consumption (230 V AC) | 3500 W |
| Current Control function | yes, through MasterBus |
| Power factor control | > 0.95 |
| Temperature range (ambient temp.) | -25 °C to 80 °C, derating > 40 |
| Cooling | vario fan |
| Protection degree | IP23 |
| Protections | over temperature, over load, short circuit, high/low battery voltage |
| MasterBus compatible | yes |
| Charger Status Interface (alarm contact) | yes |
