Victron Centaur Charger 24/30 (3)
£687.60
/
Tax included.
Shipping calculated at checkout.
CCH024030000
The Victron Centaur Charger 24/30 (3) is a 24V 30A marine and vehicle battery charger with three isolated outputs, each able to supply the full rated current. Its rugged aluminium case and 90 to 265 VAC universal input make it suited to demanding on-board environments.
✓
Available for collection or delivery in ~1 day
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Centaur Charger is Victron Energy's traditional analogue battery charger, built for the rigours of the marine and mobile world. The aluminium epoxy powder coated case carries a drip shield and stainless steel fixings to withstand heat, humidity and salt air, while the circuit boards are protected with an acrylic coating for maximum corrosion resistance. Temperature sensors keep the power components within their specified limits, reducing output current automatically under extreme conditions.
A universal 90 to 265 VAC input means the Centaur operates anywhere in the world at either 50 Hz or 60 Hz, and it also accepts a 90 to 400 VDC supply for AC-DC and DC-DC operation. Three isolated outputs let it charge three separate battery banks at once, with each output capable of delivering the full rated current.
Charging follows a three-stage IUoU characteristic with temperature compensation. The unit charges at bulk rate until output falls to 70% of the rated current, at which point a four-hour absorption timer begins before the charger drops to float. A DIP switch selects the optimum charge and float voltages for Flooded Lead-acid, Gel or AGM batteries.
PRODUCT DETAILS
- Three isolated outputs, each supplying the full 30 A to charge three battery banks at once
- Universal 90 to 265 VAC input for worldwide use at 50 Hz or 60 Hz
- Also accepts a 90 to 400 VDC supply for AC-DC and DC-DC operation
- Three-stage IUoU charging with internal temperature compensation
- DIP switch selectable for Flooded Lead-acid, Gel or AGM batteries
- Rugged aluminium case with drip shield and stainless steel fixings for marine use
- Temperature and current controlled fan with over temperature and short circuit protection
- Ignition protected with a total output ammeter
No exploded diagram available for this product.
No compatible transducers listed for this product.
Key specifications
| Battery voltage | 24 V |
| Charge current | 30 A |
| Number of outputs | 3 |
Charging
| Charge algorithm | IUoU (three-stage: bulk, absorption, float) |
| Charge voltage 'absorption' | 28.5 V (standard setting) |
| Charge voltage 'float' | 27.0 V (standard setting) |
| Recommended battery capacity | 120 - 300 Ah |
| Temperature compensation | Internal sensor, -2 mV/°C (-1 mV/°F) per cell |
Input
| AC input voltage range | 90 - 265 VAC |
| DC input voltage range | 90 - 400 VDC |
| Input frequency | 45 - 65 Hz |
| Power factor | 1 |
Connectivity & control
| Total output ammeter | Yes |
| Battery type selection | DIP switch (Flooded Lead-acid, Gel-Cell or AGM) |
Protection
| Protection | Output short circuit, over temperature |
| Ignition protected | Yes |
Environmental
| Operating temperature | -20 to 60°C (0 to 140°F) |
| Humidity | Max 95% (non-condensing) |
| Cooling | Forced, temperature and current controlled fan |
Physical
| Colour | Blue (RAL 5012) |
| Material | Aluminium epoxy powder coated case |
| Protection category | IP20 |
| Terminals | M8 studs (battery), screw-clamp 4 mm² / AWG 6 (AC) |
| Weight | 5 kg |
| Dimensions (h x w x d) | 437 x 239 x 110 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29, UL 1236 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3 |
No videos available for this product.
How many battery banks can the Centaur 24/30 charge at once?
It has three isolated outputs, so it can charge three separate battery banks simultaneously. Each output is capable of supplying the full rated charge current.
What input voltage does it accept?
The Centaur has a universal 90 to 265 VAC input and works at either 50 Hz or 60 Hz, so it can be used worldwide. It also accepts a 90 to 400 VDC supply for AC-DC and DC-DC operation.
Which battery types does it support?
A DIP switch selects the optimum charge and float voltages for Flooded Lead-acid, Gel-Cell or AGM batteries.
How does the three-stage charging work?
It uses an IUoU characteristic. The charger runs at bulk rate until the output falls to 70% of the rated amps, then a four-hour absorption timer begins, after which it switches to float. An internal sensor compensates the charge voltage by -2 mV per degree Celsius per cell.
What battery bank size is recommended?
For this 24V 30A model Victron recommends a battery capacity of 120 to 300 Ah.
