This product has been discontinued by Lowrance and is no longer available to buy.
Lowrance
Lowrance HDS-7 Carbon ROW with 3D StructureScan Box and Transducer
Description
The Lowrance HDS-7 Carbon was a premium 7-inch multi-touch fishfinder and chartplotter, built around an ultra-clear SolarMAX HD IPS display and a fast dual-core processor. It combined dual-channel CHIRP sonar, Broadband Sounder and StructureScan HD imaging with a 10 Hz internal GPS and integrated wireless connectivity. This variant shipped with a StructureScan 3D box and transom-mount transducer.
The HDS Carbon range has since been succeeded by the current Lowrance HDS LIVE and HDS PRO series, which carry over the same networking and transducer ecosystem. We continue to support installed HDS Carbon units with compatible transducers, covers and mounting spares.
PRODUCT DETAILS
- SolarMAX HD 7" multi-touch IPS display, >1200 nits brightness
- High-performance dual-core processor with touch and keypad control
- Built-in CHIRP and Broadband Sounder for clear target separation
- StructureScan HD (and TotalScan/ForwardScan support) for detailed imaging
- Internal 10 Hz GPS/GLONASS with integrated wireless and Bluetooth
- Dual microSD slots, Ethernet and NMEA 2000 networking
- Supplied with StructureScan 3D module and transducer
No exploded diagram available for this product.
No compatible transducers listed for this product.
Lowrance Active Imaging 3 in 1 Transducer 1.8m cable
Lowrance Active Imaging Transducer SideScan and DownScan 7.6m cable
Lowrance HDI Skimmer® Transom Mount transducer
Lowrance HDI Skimmer® Transom Mount transducer with Temperature
Lowrance, Branded XSonic Skimmer HDI 83-200, 455-800 kHz Transom Mount Transducer
Lowrance Active Target Live Sonar, Transducer Module and Cables
Lowrance ActiveTarget 2 (Module + Transducer + Mounts)
Lowrance HST - WSBL 83/200kHz transom-mount skimmer depth/temp
Lowrance Airmar TM150M Transom-Mount Transducer
Lowrance B175M (20°) - Bronze 1kW Medium-CHIRP Through Hull Depth/Temperature Transducer.
Lowrance Point-1 GPS Glonass With Electronic Compass
Lowrance Remote Controller LR-1 (HDS LIVE, HDS Carbon)
Display
| Screen size | 7" (diagonal) |
| Resolution | 1024 x 600 px |
| Type | SolarMAX HD IPS, multi-touch P-CAP |
| Brightness | >1200 nits |
Sonar
| Sonar | CHIRP (high/medium/low) + Broadband 50/83/200 kHz + StructureScan 455/800 kHz |
| Sonar output power | 500 W RMS |
Navigation
| GPS | Internal 10 Hz, GPS + GLONASS, WAAS/MSAS/EGNOS |
Connectivity
| NMEA 2000 | Micro-C (1) |
| NMEA 0183 | Input/output, up to 38400 baud |
| Wireless | Internal Wi-Fi 802.11 b/g/n + Bluetooth |
| Card slots | 2x microSD |
Electrical
| Supply voltage | 12 V DC (10.8 - 17.0 V DC) |
| Power consumption (max) | 24 W (2.3 A @ 13.8 V DC) |
| Recommended fuse | 5 A |
Environment
| Operating temperature | -15 C to +55 C |
| Waterproof rating | IPX6 and IPX7 |
Physical
| Weight (display only) | 1.13 kg |
General
| Warranty | 2 years |
