Victron SmartSolar MPPT 150/35 Solar Charge Controller
£213.60
/
Tax included.
Shipping calculated at checkout.
SCC115035210
Victron SmartSolar MPPT 150/35 solar charge controller for 12 V, 24 V and 48 V systems, with a 150 V maximum PV input, 35 A charge current and built-in Bluetooth.
✓
Available for collection or delivery in ~2 days
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The SmartSolar MPPT 150/35 is an ultra-fast maximum power point tracking solar charge controller from Victron Energy, accepting a solar array of up to 150 V and delivering 35 A of charge current into 12 V, 24 V or 48 V battery banks with automatic voltage selection. The ultra-fast MPPT improves energy harvest by up to 30 per cent compared with a PWM controller and by up to 10 per cent compared with a slower MPPT, with peak conversion efficiency above 98 per cent and no cooling fan.
The higher 150 V PV input allows longer panel strings, which can reduce cable losses and simplify wiring on larger arrays. Built-in Bluetooth provides wireless setup, monitoring and firmware updates through the free VictronConnect app, while the VE.Direct port gives a wired connection to a GX device or PC for system monitoring through the VRM portal.
Extensive electronic protection covers PV reverse polarity, PV short circuit and over-temperature with power derating. A multi-stage adaptive charge algorithm with eight pre-programmed profiles, internal temperature compensation and a fully discharged battery recovery function keep batteries healthy, and optional external sensing via a Smart Battery Sense or BMV-712 improves charging accuracy.
PRODUCT DETAILS
- Ultra-fast MPPT tracking for up to 30 per cent more yield than PWM
- 150 V maximum PV input allows longer panel strings
- 35 A charge current with automatic 12/24/48 V selection
- Peak efficiency above 98 per cent with no cooling fan
- Built-in Bluetooth for setup and monitoring via VictronConnect
- VE.Direct port for wired connection to a GX device or PC
- PV reverse polarity, short circuit and over-temperature protection
- Multi-stage adaptive charging with temperature compensation
No exploded diagram available for this product.
No compatible transducers listed for this product.
Victron Cerbo GX MK2
Victron GX Touch 50 Display
Victron GX Touch 70 Display
Victron Ekrano GX
Victron SmartShunt IP65 500A Battery Monitor
Victron SmartShunt IP65 1000A Battery Monitor
Victron Lithium Battery Smart 12.8V/50Ah
Victron Lithium Battery Smart 12.8V/100Ah
Victron Lithium Battery Smart 12.8V/160Ah
Victron Lithium Battery Smart 12.8V/180Ah
Victron Lithium Battery Smart 12.8V/200Ah
Victron Lithium Battery Smart 25.6V/100Ah
Victron Lithium Battery Smart 25.6V/200Ah
Key specifications
| Battery voltage | 12/24/48 V auto select (36 V via software tool) |
| Maximum PV open circuit voltage | 150 V absolute maximum (145 V start-up and operating maximum) |
| Rated charge current | 35 A |
| Nominal PV power, 12V | 500 W |
| Nominal PV power, 24V | 1000 W |
| Nominal PV power, 48V | 2000 W |
| Maximum PV short circuit current | 40 A |
| Maximum efficiency | 98 % |
Charging
| Charge voltage 'absorption' | 14.4 / 28.8 / 43.2 / 57.6 V (adjustable) |
| Charge voltage 'float' | 13.8 / 27.6 / 41.4 / 55.2 V (adjustable) |
| Charge algorithm | Multi-stage adaptive (eight pre-programmed algorithms) |
| Temperature compensation | -16 mV / -32 mV / -64 mV / degC |
| Self-consumption | 12 V: 20 mA. 24 V: 15 mA. 48 V: 10 mA |
| Automatic battery voltage recognition | 12/24/48 V auto select |
Connectivity & control
| Bluetooth | Built-in Bluetooth Smart |
| Data communication port | VE.Direct |
| Battery voltage/temperature sensing | Internal temperature sensor. Optional external sensing via Bluetooth (Smart Battery Sense or BMV-712) |
Protection
| Protection | PV reverse polarity, output short circuit, over temperature |
Environmental
| Operating temperature | -30 to +60 (full rated output up to 40) |
| Humidity | 95 %, non-condensing |
Physical
| Colour | Blue (RAL 5012) |
| Power terminals | 16 mm2 / AWG6 |
| Protection category | IP43 (electronics), IP22 (connection area) |
| Weight | 1.25 kg |
| Dimensions (h x w x d) | 130 x 186 x 70 mm |
Conformance
| Safety | EN/IEC 62109-1, UL 1741, CSA C22.2 |
What is the difference between MPPT and PWM charging?
An MPPT controller continuously tracks the maximum power point of the solar array, converting excess panel voltage into extra charge current. Victron states this ultra-fast MPPT improves energy harvest by up to 30 per cent compared with a PWM controller, and by up to 10 per cent compared with a slower MPPT, especially under changing light.
Does the 150/35 have Bluetooth?
Yes. Bluetooth Smart is built in, so you can set up, monitor, update and synchronise the controller wirelessly using the free VictronConnect app on a phone or tablet.
How do I connect it to a GX device or PC?
The controller has a VE.Direct port for a wired data connection to a Color Control GX, other GX products, a PC or other devices, enabling monitoring through the Victron VRM portal.
How do I size the solar array?
The maximum PV open circuit voltage is 150 V absolute (145 V at start-up and operating), and the maximum PV short circuit current is 40 A. Nominal PV power is 500 W at 12 V, 1000 W at 24 V and 2000 W at 48 V. Keep the array open circuit voltage below the limit in the coldest expected conditions.
Does it work with 48 V battery banks?
Yes. The 150/35 automatically selects 12 V, 24 V or 48 V (36 V can be set with the software tool), and the charge voltages adapt accordingly for each system voltage.
